Denon AVR-2105 Service Manual

85
AVR-2105/885 / AVC-1890
Q1023 00D 963 0102 803 Transistor 2SA933S
Q1024 00D 960 0005 202 Transistor KTC3198Y
Q1025 00D 960 0005 105 Transistor KTA1266Y
Q1026 00D 960 0005 105 Transistor KTA1266Y
Q1027 00D 960 0005 105 Transistor KTA1266Y
Q1028 00D 960 0005 202 Transistor KTC3198Y
Q1029 00D 960 0005 105 Transistor KTA1266Y
Q1030 00D 960 0005 202 Transistor KTC3198Y
Q1150 00D 963 0159 102 Transistor KRC111S *
Q1151 00D 960 0068 207 Transistor KTA1504Y
Q1152 00D 963 0159 102 Transistor KRC111S *
Q1153 00D 960 0068 207 Transistor KTA1504Y
Q1155 00D 963 0159 102 Transistor KRC111S *
Q1156 00D 960 0068 207 Transistor KTA1504Y
Q1157 00D 963 0159 102 Transistor KRC111S *
Q1158 00D 960 0068 207 Transistor KTA1504Y
Q1159 00D 960 0068 207 Transistor KTA1504Y
Q1160 00D 963 0159 102 Transistor KRC111S *
Q1161 00D 963 0159 102 Transistor KRC111S *
Q1162 00D 960 0068 207 Transistor KTA1504Y
Q207T 00D 960 0196 807 Transistor 2SK117Y
Q208T 00D 960 0196 807 Transistor 2SK117Y
Q209T 00D 960 0097 003 Transistor KRA104M
Q210T 00D 963 0121 004 Transistor KRC104M
Q551SW 00D 963 0044 301 Transistor KTC2875B
Q552SW 00D 963 0044 301 Transistor KTC2875B
Q601E 00D 960 0005 105 Transistor KTA1266Y
Q602E 00D 960 0005 105 Transistor KTA1266Y
Q603E 00D 960 0005 105 Transistor KTA1266Y
D1000 00D 960 0197 000 Diode KDS160
D1001 00D 960 0197 000 Diode KDS160
D1002 00D 960 0197 000 Diode KDS160
D1003 00D 960 0197 000 Diode KDS160
D1004 00D 960 0197 000 Diode KDS160
D1005 00D 960 0197 000 Diode KDS160
D1012 00D 963 0020 309 Diode 1SS133T
D1014 00D 963 0020 309 Diode 1SS133T
D1150 00D 960 0197 000 Diode KDS160
D1151 00D 960 0197 000 Diode KDS160
D1152 00D 960 0197 000 Diode KDS160
D1153 00D 960 0197 000 Diode KDS160
D1154 00D 960 0197 000 Diode KDS160
D1155 00D 960 0197 000 Diode KDS160
D1157 00D 960 0197 000 Diode KDS160
D1158 00D 960 0197 000 Diode KDS160
D205T 00D 960 0197 000 Diode KDS160
D207T 00D 960 0197 000 Diode KDS160
D251 00D 960 0197 000 Diode KDS160
D252 00D 960 0197 000 Diode KDS160
D253 00D 960 0197 000 Diode KDS160
D254 00D 960 0197 000 Diode KDS160
D255 00D 960 0197 000 Diode KDS160
D256 00D 960 0197 000 Diode KDS160
D901 00D 960 0197 000 Diode KDS160
D902 00D 960 0197 000 Diode KDS160
D903 00D 960 0197 000 Diode KDS160
D904 00D 960 0197 000 Diode KDS160
ZD1000 00D 960 0095 500 Zener diode MTZJ5.1B
ZD701M 00D 960 0095 500 Zener diode MTZJ5.1B
Ref. No. Part No. Part Name Remarks New
