Denon AVR-2105 Service Manual

86
AVR-2105/885 / AVC-1890
RESISTORS GROUP
R1031 00D 963 9005 639 Metal film 100 ohm 1W
R1038 00D 963 9005 639 Metal film 100 ohm 1W
R1059 00D 963 9005 639 Metal film 100 ohm 1W
R1095 00D 963 0018 007 Metal film 100 ohm 1/4W
R1163 00D 963 9005 639 Metal film 100 ohm 1W
R1166 00D 963 9005 639 Metal film 100 ohm 1W
R1193 00D 963 9005 639 Metal film 100 ohm 1W
R1199 00D 963 9005 639 Metal film 100 ohm 1W
R1232 00D 963 9005 639 Metal film 100 ohm 1W
R1239 00D 963 9005 639 Metal film 100 ohm 1W
R229T 00D 963 9005 639 Metal film 100 ohm 1W
R230T 00D 963 9005 639 Metal film 100 ohm 1W
R738M 00D 963 9005 338 Carbon chip 1.6 kohm 1/10W
CAPACITORS GROUP
C1000 00D 963 9006 382 Electrolytic 22uF/25V
C1001 00D 963 9006 382 Electrolytic 22uF/25V
C1002 00D 963 9005 312 Electrolytic 100uF/10V
C1003 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1004 00D 963 9006 308 Electrolytic 10uF/50V
C1005 00D 963 9006 308 Electrolytic 10uF/50V
C1006 00D 963 9006 382 Electrolytic 22uF/25V
C1007 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1009 00D 963 9006 308 Electrolytic 10uF/50V
C1010 00D 963 9006 405 Electrolytic 2.2uF/50V
C1011 00D 963 9006 405 Electrolytic 2.2uF/50V
C1013 00D 963 9006 382 Electrolytic 22uF/25V
C1014 00D 963 9006 308 Electrolytic 10uF/50V
C1016 00D 963 9006 146 Ceramic chip 560pF/50V
C1017 00D 963 9004 575 Ceramic chip 100pF/50V
C1018 00D 963 9004 575 Ceramic chip 100pF/50V
C1019 00D 963 9006 308 Electrolytic 10uF/50V
C1020 00D 963 9006 463 Electrolytic 470uF/6.3V
C1021 00D 963 9006 560 Electrolytic 47uF/35V
C1022 00D 963 9006 308 Electrolytic 10uF/50V
C1023 00D 963 9006 463 Electrolytic 470uF/6.3V
C1024 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1025 00D 963 9006 515 Ceramic 1pF/50V
C1026 00D 963 9006 308 Electrolytic 10uF/50V
C1027 00D 963 9006 463 Electrolytic 470uF/6.3V
C1030 00D 963 9006 434 Electrolytic 47uF/16V
C1034 00D 963 9006 515 Ceramic 1pF/50V
C1035 00D 963 9006 560 Electrolytic 47uF/35V
C1039 00D 963 9006 528 Ceramic chip 20pF/50V
C1040 00D 963 9006 379 Electrolytic 1uF/50V
C1041 00D 963 0157 706 Ceramic chip 0.022uF/50V *
C1042 00D 963 9006 434 Electrolytic 47uF/16V
C1049 00D 963 9006 528 Ceramic chip 20pF/50V
C1052 00D 963 9006 308 Electrolytic 10uF/50V
C1053 00D 963 9006 308 Electrolytic 10uF/50V
C1054 00D 963 9005 998 Ceramic chip 24pF/50V
C1055 00D 963 9004 753 Ceramic chip 0.047uF/50V
C1056 00D 963 9006 379 Electrolytic 1uF/50V
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
