Denon AVR-2105 Service Manual

89
AVR-2105/885 / AVC-1890
C618E 00D 963 9006 379 Electrolytic 1uF/50V
C620E 00D 963 9006 476 Electrolytic 4.7uF/50V
C621E 00D 963 0157 706 Ceramic chip 0.022uF/50V *
C622E 00D 963 9005 312 Electrolytic 100uF/10V
C623E 00D 963 9006 476 Electrolytic 4.7uF/50V
C624E 00D 963 9006 476 Electrolytic 4.7uF/50V
C625E 00D 963 9006 379 Electrolytic 1uF/50V
C627E 00D 963 0157 706 Ceramic chip 0.022uF/50V *
C628E 00D 963 9005 312 Electrolytic 100uF/10V
C632E 00D 963 9006 476 Electrolytic 4.7uF/50V
C633E 00D 963 9006 379 Electrolytic 1uF/50V
C635E 00D 963 9006 476 Electrolytic 4.7uF/50V
C636E 00D 963 0157 706 Ceramic chip 0.022uF/50V *
C637E 00D 963 9005 312 Electrolytic 100uF/10V
C638E 00D 963 9006 476 Electrolytic 4.7uF/50V
C639E 00D 963 9006 476 Electrolytic 4.7uF/50V
C640E 00D 963 9006 476 Electrolytic 4.7uF/50V
C641E 00D 963 9006 476 Electrolytic 4.7uF/50V
C702L 00D 963 9004 575 Ceramic chip 100pF/50V
C702R 00D 963 9004 575 Ceramic chip 100pF/50V
C703L 00D 963 9004 575 Ceramic chip 100pF/50V
C703R 00D 963 9004 575 Ceramic chip 100pF/50V
C704L 00D 963 9004 575 Ceramic chip 100pF/50V
C704R 00D 963 9004 575 Ceramic chip 100pF/50V
C705L 00D 963 9004 575 Ceramic chip 100pF/50V
C705R 00D 963 9004 575 Ceramic chip 100pF/50V
C709L 00D 963 9006 308 Electrolytic 10uF/50V
C709R 00D 963 9006 308 Electrolytic 10uF/50V
C711L 00D 963 9006 557 Electrolytic 220uF/6.3V
C711R 00D 963 9006 557 Electrolytic 220uF/6.3V
C712L 00D 963 9004 779 Mylar film 0.024uF/50V
C712R 00D 963 9004 779 Mylar film 0.024uF/50V
C713L 00D 960 9008 695 Mylar film 0.0068uF/100V
C713R 00D 960 9008 695 Mylar film 0.0068uF/100V
C714L 00D 963 9006 476 Electrolytic 4.7uF/50V
C714R 00D 963 9006 476 Electrolytic 4.7uF/50V
C715L 00D 963 9004 737 Ceramic chip 0.022uF/25V
C715R 00D 963 9004 737 Ceramic chip 0.022uF/25V
C716L 00D 963 9006 308 Electrolytic 10uF/50V
C717L 00D 963 9004 601 Ceramic chip 220pF/50V
C717R 00D 963 9004 601 Ceramic chip 220pF/50V
C718L 00D 963 9006 421 Electrolytic 47uF/10V
C718R 00D 963 9006 421 Electrolytic 47uF/10V
C719L 00D 963 9006 379 Electrolytic 1uF/50V
C719R 00D 963 9006 379 Electrolytic 1uF/50V
C720L 00D 963 9003 152 Mylar film 0.068uF/100V
C720R 00D 963 9003 152 Mylar film 0.068uF/100V
C721L 00D 963 9003 152 Mylar film 0.068uF/100V
C721R 00D 963 9003 152 Mylar film 0.068uF/100V
C723M 00D 963 9006 379 Electrolytic 1uF/50V
C724L 00D 963 9004 698 Ceramic chip 0.01uF/50V
C724M 00D 963 9006 379 Electrolytic 1uF/50V
C724R 00D 963 9004 698 Ceramic chip 0.01uF/50V
C725 00D 963 9004 698 Ceramic chip 0.01uF/50V
C725M 00D 963 9006 379 Electrolytic 1uF/50V
C726 00D 963 9004 698 Ceramic chip 0.01uF/50V
C726M 00D 963 0157 609 Ceramic chip 150pF/50V *
C727M 00D 963 9004 575 Ceramic chip 100pF/50V
C728M 00D 963 0157 609 Ceramic chip 150pF/50V *
C729 00D 963 9004 708 Ceramic chip 0.1uF/50V
C729M 00D 963 9006 379 Electrolytic 1uF/50V
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
