Denon AVR-2105 Service Manual

90
AVR-2105/885 / AVC-1890
C730M 00D 963 9006 308 Electrolytic 10uF/50V
C737M 00D 963 9004 575 Ceramic chip 100pF/50V
C738M 00D 963 9004 698 Ceramic chip 0.01uF/50V
C901SW 00D 963 9006 476 Electrolytic 4.7uF/50V
C910 00D 963 9004 575 Ceramic chip 100pF/50V
C911 00D 960 9010 094 Ceramic chip 0.01uF/50V
C912 00D 963 9004 575 Ceramic chip 100pF/50V
C913 00D 963 9004 575 Ceramic chip 100pF/50V
C914 00D 963 9004 575 Ceramic chip 100pF/50V
C915 00D 963 9004 575 Ceramic chip 100pF/50V
C916 00D 963 9004 575 Ceramic chip 100pF/50V
C917 00D 960 9010 094 Ceramic chip 0.01uF/50V
C918 00D 963 9004 575 Ceramic chip 100pF/50V
C920 00D 963 9004 575 Ceramic chip 100pF/50V
OTHER PARTS GROUP
CB1000 00D 963 0120 908 Beads inductor
CB1001 00D 963 0120 908 Beads inductor
CB1002 00D 963 0115 609 Inductor 33uH
CB205 00D 963 0154 602 Beads inductor *
CN1000 00D 963 0086 505 7P connector socket (TUC-P)
CN1004 00D 963 0110 701 14P connector socket (TUC-P)
CN1150 00D 963 0086 505 7P connector socket (TUC-P)
CN1151 00D 963 0097 303 15P connector socket (TUC-P)
CN1154 00D 963 0097 303 15P connector socket (TUC-P)
CN403 00D 963 0086 709 11P connector socket (TUC-P)
CN508 00D 963 0159 306 9P connector cord *
CN509 00D 963 0159 209 7P connector cord *
CN557T 00D 963 0050 104 4P connector base
CN601 00D 963 0097 303 15P connector socket (TUC-P)
CN701 00D 963 0086 301 18P connector socket (TUC-P)
CN701M 00D 963 0160 104 4P connector cord *
CN703 00D 963 0086 505 7P connector socket (TUC-P)
CN805 00D 963 0097 206 8P connector socket (TUC-P)
CN806 00D 963 0086 204 19P connector socket (TUC-P)
CP556 00D 963 0060 903 15P connector base
G902 - 1P contact Ass'y
J712B 00D 963 9003 372 Carbon chip 0 ohm 1/16W
J712C 00D 963 9003 372 Carbon chip 0 ohm 1/16W
JK704 00D 960 0188 103 2P pin jack
L1000 00D 963 0131 007 Y/C SEPARATE FILTER
L701L 00D 963 0056 302 FTZ CHOKE COIL
L701R 00D 963 0056 302 FTZ CHOKE COIL
XTAL1000 00D 963 0131 405 Crystal 14.318180MHZ
- 00D 963 0101 707 Input cushion 1
- 00D 963 0094 102 PLATE INPUT 1
- 00D 963 0146 209 4P pin jack 2
- 00D 960 0268 803 6P pin jack 1
- 00D 963 0146 102 2P pin jack 2
- 00D 963 0146 209 4P pin jack 1
Ref. No. Part No. Part Name Remarks New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2105 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.08% THD)
Number of Channels	7.1
Component Video Inputs	3
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	102 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Digital Sound Processor (DSP)	Yes
HDMI Switching	No
Video Conversion/Scaling	No
Output Impedance / Channel	8 ohm
Frequency Response	10 Hz - 100 kHz
Total Harmonic Distortion	0.08%
Dolby Decoding	Dolby Digital, Dolby Pro Logic II
DTS Decoding	DTS, DTS Neo:6
Digital Audio Inputs	2 coaxial, 5 optical
Audio D/A Converter	24bit / 192kHz
Tuner Frequency Range	AM: 522 - 1611kHz, FM: 87.5 - 108MHz
Dimensions (W x H x D)	434 x 171 x 377 mm
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
