Denon AVR-2106 Service Manual

39
AVR-2106/886
D133 00D 963 0046 202 D,ZENER MTZJ18B
D134 00D 963 0046 202 D,ZENER MTZJ18B
D135 00D 963 0020 309 D, 1SS133
D136 00D 963 0058 601 D,ZENER MTZJ12B
D137 00D 963 0020 309 D, 1SS133
D138A 00D 963 0058 407 D, 1N4007
D141 00D 963 0058 407 D, 1N4007
D142 00D 963 0058 407 D, 1N4007
D143 00D 963 0058 407 D, 1N4007
D144 00D 963 0058 407 D, 1N4007
D145 00D 963 0058 407 D, 1N4007
D146 00D 963 0058 407 D, 1N4007
D148 00D 963 0020 309 D, 1SS133
D149 00D 963 0058 407 D, 1N4007
D150 00D 963 0058 407 D, 1N4007
D151 00D 963 0020 309 D, 1SS133
D152 00D 963 0058 407 D, 1N4007
D153 00D 963 0058 407 D, 1N4007
D154 00D 960 0095 704 D,ZENER MTZJ6.2B
D157 00D 963 0219 903 D,ZENER MTZJ16B
D158 00D 963 0020 309 D, 1SS133
D159 00D 963 0020 309 D, 1SS133
D160 00D 963 0020 309 D, 1SS133
ZD310 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD311 00D 960 0095 500 D,ZENER MTZJ5.1B
LED901 00D 963 0148 605 LED, SML1216W (RED/GREEN)
RESISTORS GROUP
R104C 00D 963 9006 285 R,FIXED 1WJ-5.6K
R104FL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R104FR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R104SL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R104SR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105C 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105FL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105FR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105SL 00D 963 9006 285 R,FIXED 1WJ-5.6K
R105SR 00D 963 9006 285 R,FIXED 1WJ-5.6K
R106C 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R106FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R106FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R106SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R106SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107C 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107FL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107FR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107SL 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R107SR 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R108C 00D 963 9006 269 R,FIXED 1WJ-0.22
R108FL 00D 963 9006 269 R,FIXED 1WJ-0.22
R108FR 00D 963 9006 269 R,FIXED 1WJ-0.22
R108SL 00D 963 9006 269 R,FIXED 1WJ-0.22
R108SR 00D 963 9006 269 R,FIXED 1WJ-0.22
R109C 00D 963 9006 269 R,FIXED 1WJ-0.22
R109FL 00D 963 9006 269 R,FIXED 1WJ-0.22
R109FR 00D 963 9006 269 R,FIXED 1WJ-0.22
R109SL 00D 963 9006 269 R,FIXED 1WJ-0.22
R109SR 00D 963 9006 269 R,FIXED 1WJ-0.22
R110C 00D 963 9006 269 R,FIXED 1WJ-0.22
R110FL 00D 963 9006 269 R,FIXED 1WJ-0.22
R110FR 00D 963 9006 269 R,FIXED 1WJ-0.22
R110SL 00D 963 9006 269 R,FIXED 1WJ-0.22
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
