Denon AVR-2106 Service Manual

44
AVR-2106/886
CPU P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D 262 3537 000 IC M30622MGP *
IC272 00D 963 0219 301 IC CJ7806
IC273 00D 963 0235 107 IC CJ7906F
IC274 00D 963 0147 606 IC KIA78R09API
IC301 00D 960 0180 004 IC LC75721E
IC302 00D 963 0074 504 IC BU2090F
IC803 00D 963 0237 503 JSR1165-C /OPTICAL
Q201 00D 960 0285 006 TR KRC104S
Q202 00D 963 0121 509 TR KTC3875S
Q203 00D 960 0196 603 TR KTC2874B
Q204 00D 960 0196 603 TR KTC2874B
Q205 00D 960 0097 207 TR KRA102M
Q206 00D 960 0196 603 TR KTC2874B
Q207 00D 960 0196 603 TR KTC2874B
Q218 00D 963 0102 803 TR 2SA933S
Q300 00D 963 0121 402 TR KRA104S
Q301 00D 963 0121 402 TR KRA104S
Q302 00D 960 0285 006 TR KRC104S
Q303 00D 960 0285 006 TR KRC104S
Q304 00D 960 0285 006 TR KRC104S
Q305 00D 963 0121 402 TR KRA104S
Q306 00D 963 0120 704 TR KRA102S
Q307 00D 963 0121 606 TR KRC107S
Q308 00D 963 0120 704 TR KRA102S
Q309 00D 963 0121 402 TR KRA104S
Q565 00D 963 0120 704 TR KRA102S
D202 00D 963 0058 407 D, 1N4007
D203 00D 963 0219 709 D, 1N4148W
D204 00D 963 0020 309 D, 1SS133
D208 00D 963 0020 309 D, 1SS133
D209 00D 963 0020 309 D, 1SS133
D210 00D 963 0020 309 D, 1SS133
D211 00D 963 0219 709 D, 1N4148W
D302 00D 963 0020 309 D, 1SS133
D303 00D 963 0020 309 D, 1SS133
D304 00D 963 0020 309 D, 1SS133
D305 00D 963 0219 709 D, 1N4148W
D306 00D 963 0219 709 D, 1N4148W
D307 00D 963 0219 709 D, 1N4148W
ZD201 00D 963 0047 502 D,ZENER MTZJ3.3B
ZD301 00D 960 0095 801 D,ZENER MTZJ6.8B
ZD302 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD303 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD304 00D 960 0095 500 D,ZENER MTZJ5.1B
ZD305 00D 960 0095 500 D,ZENER MTZJ5.1B
LED301 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED302 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED305 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED306 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED307 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED308 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED309 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED310 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
LED311 00D 960 0197 204 LED PI5-RD/HL50RDRF4T
FL301 00D 963 0219 806 DISPLAY,FLT 16-ST-82GNK
