Denon AVR-2106 Service Manual

45
AVR-2106/886
RESISTORS GROUP
R272 00D 963 0215 907 R,METAL FILM 4.7-J,1W
R282 00D 960 9003 807 R,METAL FILM 100-J,1/4W
CAPACITORS GROUP
C201 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C202 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C203 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C204 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C205 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C213 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C214 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C215 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C216 nsp 00D 963 9004 711 C,CERAMIC CHIP 0.1UF-Z/50V
C221 00D 960 9009 911 C,ELECT 100UF-M/10V
C261 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C262 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C263 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C267 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C268 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C269 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C270 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C273 00D 963 0234 205 C,ELECT 10UF-M/50V
C274 00D 963 0234 205 C,ELECT 10UF-M/50V
C276 00D 963 0234 205 C,ELECT 10UF-M/50V
C277 00D 963 0234 205 C,ELECT 10UF-M/50V
C292 00D 960 9003 108 C,CERAMIC 0.022UF-Z/25V
C294 nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C296 00D 963 0233 109 C,CERAMIC 0.01UF-Z/50V
C301 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C301O 00D 963 0234 409 C,ELECT 47UF-M/10V
C302 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C302O 00D 963 0020 202 C,CERAMIC 0.1UF-Z/50V
C303 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C303O 00D 963 9004 591 C,CERAMIC 22PF-J/50V
C304 00D 963 0233 303 C,CERAMIC 0.01UF-M/16V
C305 nsp 00D 963 0224 105 C,CERAMIC CHIP 1000PF-K/50V
C306 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C307 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C308 00D 960 9010 816 C,CERAMIC 0.1UF-Z/50V
C309 nsp 00D 963 0224 202 C,CERAMIC CHIP 0.022UF-K/25V
C310 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C311 nsp 00D 963 0233 701 C,CERAMIC CHIP 30PF-J/50V
C312 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C314 00D 963 0021 900 C,FILM 0.047UF-J/100V
C315 00D 963 9005 749 C,ELECT 1UF-M/50V
C316 00D 963 0234 205 C,ELECT 10UF-M/50V
C317 00D 963 9005 859 C,ELECT 47UF-M/16V
C318 00D 963 0216 702 C,FILM 0.047UF-J/63V
C319 00D 963 9005 862 C,ELECT 47UF-M/16V
C320 00D 963 9005 749 C,ELECT 1UF-M/50V
C321 00D 963 0021 900 C,FILM 0.047UF-J/100V
C322 00D 963 9005 862 C,ELECT 47UF-M/16V
C323 00D 963 0216 401 C,FILM 0.1UF-J/100V
C324 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C325 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C326 00D 963 9006 544 C,ELECT 22UF-M/25V
C327 00D 960 9010 010 C,ELECT 4.7UF-M/50V
C328 nsp 00D 963 0234 001 C,CERAMIC CHIP 0.047UF-Z/50V
C329 00D 963 9006 531 C,ELECT 22UF-M/16V
C330 00D 963 9006 531 C,ELECT 22UF-M/16V
C340 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C341 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C347 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
