Denon AVR-2106 Service Manual

46
AVR-2106/886
C348 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C354 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
BC201 00D 254 4666 005 CE04W0H105ZC(FG)
OTHER PARTS GROUP
BD201 nsp 00D 963 0154 602 BEAD,COIL
BD203 nsp 00D 963 0154 602 BEAD,COIL
BD204 nsp 00D 963 0234 603 COIL,BEAD
BD207 nsp 00D 963 0154 602 BEAD,COIL
BD301 nsp 00D 963 0220 002 BEAD,COIL 121JT
BD303 nsp 00D 963 0220 002 BEAD,COIL 121JT
BD304 nsp 00D 963 0220 002 BEAD,COIL 121JT
CN302 nsp 00D 963 0116 501 CN,WIRE 150MM/5P
CN391 nsp 00D 963 0160 502 CN,WIRE 80MM/8P
CN392 nsp 00D 963 0160 308 CN,WIRE 70MM/3P
CN605 nsp 00D 963 0159 908 CN,WIRE 160MM/3P
CN606 nsp 00D 963 0159 607 CN,WIRE 130MM/4P
CP1001 nsp 00D 963 0206 408 CN.WAFER 7P
CP1003 nsp 00D 963 0097 400 CN.WAFER 8P for AVR2106E3
CP1004 nsp 00D 960 0239 609 CN.WAFER 13P
CP201 nsp 00D 963 0087 407 CN.WAFER 16P
CP201A nsp 00D 963 0206 408 CN.WAFER 7P for AVR2106E3
CP202 nsp 00D 963 0097 507 CN.WAFER 15P
CP202A nsp 00D 963 0206 408 CN.WAFER 7P for AVR2106E3
CP204X nsp 00D 963 0097 400 CN.WAFER 8P
CP205 nsp 00D 963 0060 709 CN.WAFER 8P
CP301A nsp 00D 963 0161 006 CN.FPC 23P
CP301B nsp 00D 963 0161 103 CN.FPC 23P
CP302 nsp 00D 963 0066 101 CN.WAFER 5P
CP303 nsp 00D 963 0236 009 CN.WAFER 3P
CP552 nsp 00D 963 0087 601 CN.WAFER 18P
CP553 nsp 00D 963 0111 108 CN.WAFER 14P
CP605 nsp 00D 963 0235 806 CN.WAFER 3P
CP606 nsp 00D 963 0235 903 CN.WAFER 4P
CP701 nsp 00D 963 0087 805 CN.WAFER 11P
CP702 nsp 00D 963 0087 504 CN.WAFER 19P
CP703 nsp 00D 963 0111 108 CN.WAFER 14P
CP704 nsp 00D 963 0087 805 CN.WAFER 11P
CP801 nsp 00D 963 0087 601 CN.WAFER 18P
CP802 nsp 00D 963 0087 504 CN.WAFER 19P
CP803 nsp 00D 963 0111 108 CN.WAFER 14P
G301 - RING,TER WIRE 80MM/1P
G302 - RING,TER WIRE 80MM/1P
GND01 - TERMINAL, EARTH
GND02 - TERMINAL, EARTH
JIG601 00D 960 0123 605 CN.WAFER 13P
L301 nsp 00D 960 0010 307 COIL,INDUCTOR 10UH
L301O nsp 00D 960 0215 908 COIL,INDUCTOR 4.7UH
L302 nsp 00D 960 0128 008 COIL,INDUCTOR 100UH
RMC301 00D 963 0217 808 MODULE,REMOCON NJL34H380A
SW301C 00D 963 0200 103 SW,TACT SKHV10920A
SW302A 00D 963 0095 305 SW,TACT SKHV10910D01
SW302B 00D 963 0095 305 SW,TACT SKHV10910D01
SW302C 00D 963 0200 103 SW,TACT SKHV10920A
SW303A 00D 963 0095 305 SW,TACT SKHV10910D01
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
