Denon AVR-2106 Service Manual

47
AVR-2106/886
SW303B 00D 963 0095 305 SW,TACT SKHV10910D01
SW303C 00D 963 0200 103 SW,TACT SKHV10920A
SW304A 00D 963 0095 305 SW,TACT SKHV10910D01
SW304B 00D 963 0095 305 SW,TACT SKHV10910D01
SW304C 00D 963 0200 103 SW,TACT SKHV10920A
SW305A 00D 963 0095 305 SW,TACT SKHV10910D01
SW305B 00D 963 0200 103 SW,TACT SKHV10920A
SW305C 00D 963 0200 103 SW,TACT SKHV10920A
SW306A 00D 963 0095 305 SW,TACT SKHV10910D01
SW306B 00D 963 0095 305 SW,TACT SKHV10910D01
SW306C 00D 963 0200 103 SW,TACT SKHV10920A
SW307A 00D 963 0095 305 SW,TACT SKHV10910D01
SW307C 00D 963 0200 103 SW,TACT SKHV10920A
SW308A 00D 963 0095 305 SW,TACT SKHV10910D01
SW308C 00D 963 0200 103 SW,TACT SKHV10920A
SW309A 00D 963 0095 305 SW,TACT SKHV10910D01
SW309C 00D 963 0200 103 SW,TACT SKHV10920A
VEC301 00D 963 0095 208 SW,ENCODER EC16B24SA
VEC302 00D 963 0095 208 SW,ENCODER EC16B24SA
X203 00D 963 0217 701 RESONATOR,CERAMIC ZTT12.00MT
00D 963 0158 307 JACK,DIN
00D 963 0146 403 TER,RCA 3PIN
-HEAT SINK
nsp 00D 963 0018 007 SCREW, 3*8 B-TYPE ZNY/BH
nsp 00D 960 0184 408 HOLDER, FLT
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
