Denon AVR-2106 Service Manual

53
AVR-2106/886
INPUT P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201T 00D 963 0158 909 IC TC94A27BUG
IC202T 00D 963 0158 909 IC TC94A27BUG
IC203T 00D 960 0080 201 IC TC9164CNG
IC205 00D 963 0202 305 IC NJM2068M
IC206 00D 963 0202 305 IC NJM2068M
IC207 00D 963 0202 305 IC NJM2068M
IC208 00D 963 0159 005 IC NJM5532M
IC209 00D 963 0159 005 IC NJM5532M
IC210 00D 963 0159 005 IC NJM5532M
IC211 00D 963 0159 005 IC NJM5532M
IC701 00D 963 0083 207 IC TC9274CNG-011
IC701M 00D 963 0202 305 IC NJM2068M
IC702 00D 963 0202 305 IC NJM2068M
IC704 00D 960 0174 502 IC NJM2068DD
IC705 00D 960 0174 201 IC TC9273CNG-004
IC707 00D 963 0202 305 IC NJM2068M
IC708 00D 963 0202 305 IC NJM2068M
IC1000 00D 963 0083 304 IC BA7626F
IC1001 00D 963 0116 103 IC MM74HC4053MX
IC1002 00D 963 0083 304 IC BA7626F
IC1003 00D 963 0074 504 IC BU2090F
IC1004 00D 963 0116 103 IC MM74HC4053MX
IC1005 00D 963 0074 504 IC BU2090F
IC1006 00D 963 0116 307 IC LC74781
IC1007 00D 963 0116 200 IC NJM2274R
IC1008 00D 963 0116 103 IC MM74HC4053MX
IC1009 00D 262 3110 906 IC TC90A69F +REF
IC1010 00D 263 1082 903 IC TK15420MTL +C
IC1011 00D 263 1082 903 IC TK15420MTL +C
IC1012 00D 263 1082 903 IC TK15420MTL +C
IC1013 00D 263 1082 903 IC TK15420MTL +C
IC1015 00D 263 1082 903 IC TK15420MTL +C
IC1016 00D 263 1082 903 IC TK15420MTL +C
IC1150 00D 963 0083 304 IC BA7626F
IC1151 00D 963 0083 304 IC BA7626F
IC1152 00D 963 0083 304 IC BA7626F
IC1153 00D 963 0083 304 IC BA7626F
IC1154 00D 262 3108 002 IC TA1270BF +REF
IC1155 00D 963 0148 207 IC LA7108M
IC1157 00D 263 1082 903 IC TK15420MTL +C
Q207T 00D 960 0196 807 FET 2SK117Y
Q208T 00D 960 0196 807 FET 2SK117Y
Q209T 00D 960 0097 003 TR KRA104M
Q210T 00D 963 0121 004 TR KRC104M
Q601C 00D 963 0219 602 TR KRC106M
Q602C 00D 963 0219 602 TR KRC106M
Q603C 00D 963 0219 602 TR KRC106M
Q604C 00D 963 0219 602 TR KRC106M
Q605C 00D 960 0111 808 TR KRC107S
Q606 00D 963 0219 602 TR KRC106M
Q606C 00D 963 0102 803 TR 2SA933S
Q607C 00D 963 0120 801 TR KRC102S
Q608C 00D 963 0219 602 TR KRC106M
Q609C 00D 963 0219 602 TR KRC106M
Q610C 00D 963 0219 602 TR KRC106M
Q701 00D 963 0121 208 TR KRC107M
Q707M 00D 963 0121 208 TR KRC107M
Q1000 00D 963 0102 803 TR 2SA933S
Q1001 00D 963 0102 803 TR 2SA933S
Q1002 00D 963 0121 703 TR KRA107S
Q1003 00D 963 0121 703 TR KRA107S
Q1004 00D 963 0120 704 TR KRA102S
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
