Denon AVR-2106 Service Manual

49
AVR-2106/886
Q913FR 00D 963 0044 301 TR KTC2875B
Q913SBL 00D 963 0044 301 TR KTC2875B
Q913SBR 00D 963 0044 301 TR KTC2875B
Q913SL 00D 963 0044 301 TR KTC2875B
Q913SR 00D 963 0044 301 TR KTC2875B
Q913SW 00D 963 0044 301 TR KTC2875B
D551 00D 963 0020 309 D, 1SS133
D552 00D 963 0020 309 D, 1SS133
D552T 00D 963 0219 709 D, 1N4148W
D553 00D 963 0020 309 D, 1SS133
D554 00D 963 0020 309 D, 1SS133
D555 00D 963 0020 309 D, 1SS133
D556 00D 963 0020 309 D, 1SS133
D557 00D 963 0020 309 D, 1SS133
D559 00D 963 0020 309 D, 1SS133
D560 00D 963 0020 309 D, 1SS133
D561 00D 963 0020 309 D, 1SS133
D562 00D 963 0058 407 D, 1N4007
D563 00D 963 0058 407 D, 1N4007
D564 00D 963 0058 407 D, 1N4007
D565 00D 963 0020 309 D, 1SS133
D566 00D 963 0020 309 D, 1SS133
D567 00D 963 0020 309 D, 1SS133
D568 00D 963 0020 309 D, 1SS133
D569 00D 963 0020 309 D, 1SS133
D588 00D 963 0020 309 D, 1SS133
D901 00D 963 0219 709 D, 1N4148W
D902 00D 963 0219 709 D, 1N4148W
D903 00D 963 0219 709 D, 1N4148W
D904 00D 963 0219 709 D, 1N4148W
D1000 00D 963 0058 407 D, 1N4007
D1001 00D 963 0058 407 D, 1N4007
D1002 00D 963 0058 407 D, 1N4007
D1003 00D 963 0058 407 D, 1N4007
ZD551T 00D 963 0058 601 D,ZENER MTZJ12B
ZD564 00D 960 0095 500 D,ZENER MTZJ5.1B
RESISTORS GROUP
R509C 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509FL 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509FR 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509SBL 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509SBR 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509SL 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R509SR 00D 960 9005 902 R,METAL FILM 1.2K-J,1/4W
R511C 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511FL 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511FR 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511SBL 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511SBR 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511SL 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R511SR 00D 960 9004 301 R,METAL FILM 47-J,1/4W
R553T 00D 963 0215 800 R,METAL FILM 390-J,1W
R554T 00D 963 0236 203 R,METAL FILM 180-J,1/4W
R559 00D 960 9005 642 R,METAL FILM 1.2K-J,1W
R565 00D 960 9005 642 R,METAL FILM 1.2K-J,1W
R570 00D 960 9005 642 R,METAL FILM 1.2K-J,1W
R1000A 00D 963 0216 003 R,METAL FILM 0.22-J,1W
R1000B 00D 963 0216 003 R,METAL FILM 0.22-J,1W
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
