Denon AVR-2106 Service Manual

51
AVR-2106/886
C563 nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C577M nsp 00D 963 9004 698 C,CERAMIC CHIP 0.01UF-K/50V
C900C 00D 963 9005 778 C,ELECT 10UF-M/50V
C900FL 00D 963 9005 778 C,ELECT 10UF-M/50V
C900FR 00D 963 9005 778 C,ELECT 10UF-M/50V
C900SBL 00D 963 9005 778 C,ELECT 10UF-M/50V
C900SBR 00D 963 9005 778 C,ELECT 10UF-M/50V
C900SL 00D 963 9005 778 C,ELECT 10UF-M/50V
C900SR 00D 963 9005 778 C,ELECT 10UF-M/50V
C900SW 00D 963 9005 778 C,ELECT 10UF-M/50V
C901C 00D 963 9006 544 C,ELECT 22UF-M/25V
C901FL 00D 963 9006 544 C,ELECT 22UF-M/25V
C901FR 00D 963 9006 544 C,ELECT 22UF-M/25V
C901SBL 00D 963 9006 544 C,ELECT 22UF-M/25V
C901SBR 00D 963 9006 544 C,ELECT 22UF-M/25V
C901SL 00D 963 9006 544 C,ELECT 22UF-M/25V
C901SR 00D 963 9006 544 C,ELECT 22UF-M/25V
C901SW 00D 963 9006 544 C,ELECT 22UF-M/25V
C929C nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929FL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929FR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929SBL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929SBR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929SL nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929SR nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C929SW nsp 00D 963 0223 601 C,CERAMIC CHIP 100PF-J/50V
C933 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C934 nsp 00D 963 9004 708 C,CERAMIC CHIP 0.1UF-K/50V
C1000A 00D 963 0021 900 C,FILM 0.047UF-J/100V
C1000B 00D 963 0021 900 C,FILM 0.047UF-J/100V
C1001 00D 963 0021 900 C,FILM 0.047UF-J/100V
C1002 00D 963 0183 301 C,ELECT 4700UF-M/25V
C1003 00D 963 0224 804 C,ELECT 3300UF-M/25V
C1004 00D 963 0021 104 C,ELECT 6800UF-M/16V
OTHER PARTS GROUP
BKT501 nsp 00D 960 0184 000 BRACKET, SCREW
BKT502 nsp 00D 960 0184 000 BRACKET, SCREW
BKT503 nsp 00D 960 0184 000 BRACKET, SCREW
BKT505 nsp 00D 960 0184 000 BRACKET, SCREW
CN106 nsp 00D 963 0148 702 CN,WIRE 120MM/2P
CN202X nsp 00D 963 0256 005 CN,WIRE 350MM/8P *
CN501 nsp 00D 963 0205 700 CN.WAFER 5P
CN502 nsp 00D 963 0236 902 CN.WAFER 12P
CN503 nsp 00D 963 0086 505 CN.WAFER 7P
CN504 nsp 00D 963 0085 506 CN.WAFER 9P
CN505 nsp 00D 963 0086 505 CN.WAFER 7P
CN508 nsp 00D 963 0236 708 CN,WIRE 120MM/15P
CN509 nsp 00D 963 0236 601 CN,WIRE 120MM/5P
CN552 nsp 00D 963 0086 301 CN.WAFER 18P
CN553 nsp 00D 963 0110 701 CN.WAFER 14P
CN555 nsp 00D 963 0110 701 CN.WAFER 14P
CN556 nsp 00D 963 0086 709 CN.WAFER 11P
CN557 nsp 00D 963 0236 805 CN,WIRE 80MM/9P
CN559 nsp 00D 963 0159 403 CN,WIRE 100MM/15P
CN901 nsp 00D 963 0097 303 CN.WAFER 15P
CN1153 nsp 00D 963 0097 303 CN.WAFER 15P
CP102X nsp 00D 963 0066 101 CN.WAFER 5P
CP506 nsp 00D 963 0060 703 CN.WAFER 15P
CP508 nsp 00D 963 0060 703 CN.WAFER 15P
CP509 nsp 00D 963 0066 101 CN.WAFER 5P
CP512 nsp 00D 963 0068 303 CN.WAFER 9P
Ref. No. nsp Part No. Part Name Remarks Q'ty New
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Denon AVR-2106 Specifications

Audio Specifications

front rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
center rated output	90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
surround back rated output	90 W + 90 W (8 Ω/ohms, 20 Hz ~ 20 kHz with 0.08% T.H.D.)
dynamic power	120 W x 2 ch (8 Ω/ohms)
analog input sensitivity	200 mV / 47 kΩ/kohms
frequency response	10 Hz ~ 100 kHz: +1, –3 dB (DIRECT mode)
analog distortion	0.008 % (20 Hz ~ 20 kHz) (DIRECT mode)
phono input sensitivity	2.5 mV
phono RIAA deviation	±1 dB (20 Hz to 20 kHz)
phono S/N	74 dB (A weighting, with 5 mV input)
phono rated output	150 mV / 7 V
phono distortion factor	0.03 % (1 kHz, 3 V)

Video Specifications

standard video input/output level	1 Vp-p, 75 Ω/ohms
standard video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
S-Video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
S-Video frequency response	5 Hz ~ 10 MHz — +1, –3 dB
color component video input/output level	Y (brightness) signal — 1 Vp-p, 75 Ω/ohms
color component video frequency response	DC ~ 100 MHz — +0, –3 dB

Tuner Specifications

receiving range	87.50 MHz ~ 108.00 MHz 522 kHz ~ 1611 kHz
usable sensitivity	1.0 µV (11.2 dBf) 18 µV
50 dB quieting sensitivity	MONO 1.6 µV (15.3 dBf)
S/N MONO	77 dB (IHF-A weighted)
total harmonic distortion MONO	0.15 % (1 kHz)
total harmonic distortion STEREO	0.3 % (1 kHz)

General Specifications

power supply	AC 230 V, 50 Hz
power consumption	450 W
maximum external dimensions	434 (W) x 171 (H) x 417 (D) mm
mass	12.8 kg

Remote Control Specifications

batteries	R6P/AA Type (two batteries)
external dimensions	55 (W) x 225 (H) x 34.5 (D) mm
mass	165 g (including batteries)
