Denon AVR-2113CI Service Manual

161
Pin Pin Name Symbol I/O
Pull up/
down
LvCnv STBY STOP
CEC
STBY
Function
79
PB7/A15/PO31/
TIOCA11/TIOCB11
H/P RLY O - - L L L HEADPHONE RLY control pin
80
PB6/A14/PO30/
TIOCA11
FRONT RLY O - - L L L FRONT Ch RELAY control pin
81
PB5/A13/PO29/
TIOCA10/TIOCB10
HIN SELC O - - L L L
TC74VHC4051AFT control pin.
(Control the detection of HDMI 5V
INPUT for CEC STANDBY. )
82
PB4/A12/PO28/
TIOCA10
TU_SEN O - - L L L TUNER control pin
83
PB3/A11/PO27/
TIOCC9/TIOCD9
C/S RLY O - - L L L
CENTER/SURROUND Ch RELAY
control pin
84
PB2/A10/PO26/
TIOCC9
SB RLY O - - L L L
SURROUND-BACK Ch RELAY control
pin
85
PB1/A9/PO25/
TIOCA9/TIOCB9
D5V POWER O - - L L L
DIGITAL POWER SUPPLY (D3.3V)
control pin (ON:H)
86 P74/ADTRG3# DIR CE O - - L L L DIR control pin (LC89058W-E)
87 P73 DIR DIN O - - L L L DIR control pin (LC89058W-E)
88 P72 DIR DOUT I DA3VPu - I I I DIR control pin (LC89058W-E)
89
P71/CS4#-C/
CS5#-C/CS6#-C/
CS7#-C
DIR CLK O - - L L L DIR control pin (LC89058W-E)
90
P70/CS3#-B/
ADTRG2#
DIR RST O - - L L L DIR RESET pin (LC89058W-E)
91 VCC VCC - - - - - - +3.3V
92
PB0/A8/PO24/
TIOCA9
COMP SW2 O - 3->5 L L L
A-VIDEO (COMPONENT) switcher
control pin (NJM2586M)
93 VSS VSS - - - - - - GND
94
PA7/A7/PO23/
TIOCA8/TIOCB8/
TCLKH
NC O/O -/- - L L L Unused
95
PA6/A6/PO22/
TIOCA8
VSEL A I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
96
PA5/A5/PO21/
TIOCA7/TIOCB7/
TCLKG
VSEL B I - - I I I
Master Volume rotation detection
pin(Rotary encoder)
97
PA4/A4/PO20/
TIOCA7
E POWER 2
(Reserve)
O -/- - L L L Unused
98
PA3/A3/PO19/
TIOCC6/TIOCD6/
TCLKF
DAC(ETHER)
MUTE
O - - L L L
DAC (ETHER) MUTE control pin
(PCM5100 for DM860)
99
PA2/A2/PO18/
TIOCC6/TCLKE
PRE Z2 MUTE O - - L L L
Z2 PRE OUT MUTE control pin
(AVR2113 Only)
100
PA1/A1/PO17/
TIOCA6/TIOCB6
NC O - - L L L Unused
101
PA0/A0/BC0#/PO16/
TIOCA6
PRE MUTE O - - L L L
Sub Woofer PRE OUT MUTE control
pin
102 PE7/IRQ7-A/D15
ADV8002
(AVR1913)
or ADV8003
(AVR2113) INT2
I - - I I I
HDMI TX INT2 input pin (ADV8002 or
ADV8003)
103 PE6/IRQ6-A/D14 ADV7850 INT1 I - - I I I HDMI RX INT1 input pin (ADV7850)
104 PE5/IRQ5-A/D13 ADV7850 INT2 I - - L L L HDMI RX INT2 input pin (ADV7850)
105 PE4/D12
ISEL A (AVR2113)
/ NC (AVR1913)
I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder) / NC (AVR1913)
106 PE3/D11
ISEL B (AVR2113)
/ NC (AVR1913)
I/O - - I/L I/L I/L
Input Selector rotation detection
pin(Rotary encoder) / NC (AVR1913)
107 PE2/D10 VOL CLK O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
108 PE1/D9 VOL DATA O - - L L L
FUNCTION / VOLUME control pin
(R2A15218)
109 PE0/D8 PLD WRITE O - - L L L A.PLD /JTAG switching control pin
110 PD7/D7 JTAG TDO I - - L L L A.PLD rewriting control pin (JTAG)
111 PD6/D6
JTAG TMS/APLD
CS
O/O - - L L L A.PLD rewriting & control pin
112 PD5/D5
JTAG TDI/APLD
DATA/DAC DATA
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
113 PD4/D4
JTAG TCK/APLD
CLK/DAC CLK
O/O - - L L L
A.PLD rewriting & control /DAC control
pin
114 P64/CS4#-B ADC RST O - - L L L A/D converter control pin (AK5358B)
115 P63/CS3#-A/CS7#-A NC O - - L L L Unused
