Denon AVR-2113CI Service Manual

28
3. Service Related Selection mode
3.1. Behavior specications
In this mode, you can switch between the Diagnostic mode (SERVICE CHECK), the Displaying the protection mode
(PROTECTION) and the 232C clear mode (RS232C RESET).
3.2. Starting up
Press the "Power operation (
X
)" button to turn on power while pressing the "ZONE2 SOURCE", "DIMMER" and
"STATUS" buttons.
AVR-1913E3
Press the "
SOURCE SELECT
1
" button to select the mode and press the "STATUS" button to restart the set and make the
setting take effect.
Except AVR-1913E3
Press the "TUNER PRESET CH +" button to select the mode and press the "STATUS" button to restart the set and make
the setting take effect.
q
FLD
1 . S E R V I C E C H E C K
This mode is used for conrming the Video and Audio (signal)
paths. (Diagnostic mode)
The signal paths of the set can be easily conrmed after repair.
w
FLD
2 . P R O T E C T I O N
The protection history can be checked.
e
FLD
3 . R S 2 3 2 C R E S E T
The 232C standby mode is changed to the Normal standby mode.
3.3. Canceling diagnostic mode
Turn off the power by pressing the "Power operation (
X
)" button.
