Denon AVR-2113CI Service Manual

198
Ref. No. Part No. Part Name Remarks Q'ty New
CP4002 nsp CN,WAFER C125Z1-15 15P L109012511520S
CP4003 nsp CN,WAFER C125Z1-11 11P L109012511120S
CP4004 nsp CN,WAFER C125Z1-17 17P L109012511720S
CP4140 nsp CN.WAFER 7.92MM
1913E3, 2113CIE3,
2113E1C
L108202000220S
CP4142 nsp CN.WAFER 7.92MM LWBP1143-02P L108011430210S
z
F4140 963652010510S FUSE T2A/250V 1913E3, 2113CIE3 N751502001160S
z
F4140 963652010500S FUSE T1.6A/250V 2113E2, 2113E1C N751501601160S
z
F4141 963652010520S FUSE T6.3A/250V 1913E3, 2113CIE3 N751506301160S
z
F4141 963652010910S FUSE T3.15A/250V 2113E2, 2113E1C N751503151160S
J4000-4094 nsp CN,WIRE 1P ROLL JUMPER (0.0423g) L045084055010S
J4145 nsp CN,WIRE 1P ROLL JUMPER (0.0423g) L045084055010S
J4150 nsp CN,WIRE 1P ROLL JUMPER (0.0423g) L045084055010S
J4152 nsp CN,WIRE 1P ROLL JUMPER (0.0423g) L045084055010S
J4154,4155 nsp CN,WIRE 1P ROLL JUMPER (0.0423g) L045084055010S
z
JACK4140 963641011240S SOCKET,POWER AC (INLET JACK) 2113E2 G4300152P0001S
JACK4000 963643010360S TER, BOARD 6P JB-602A-02 G613602A0200YS
JACK4001 963646001690S TER, BOARD 8P MST-108V1 G614108V1010MS
JACK4003 00D9630146005 TER,RCA 1PIN G600107A0000YS
JK4140 963641011240S SOCKET,POWER AC (INLET JACK) 2113E2 G4300152P0001S
L4000-4006 nsp SP-2507 1.0 PI*2UEW TURNS D330900001330S
z
L4140 963111100420D COIL,LINE FILTER SQ2014 27mH D320201405510S
RLY4000 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
RLY4001-
4004
963682100280D RELAY JZC-42F/012-2HST G680060103010S
z
RLY4140 963682100290D RELAY JZC-36FD/005-HLT G680060103030S
PACK4000 943183100200S TUNER,FM KST-MW004FV1-S63SV 1913E3, 2113CIE3
CNVMW004FV1-
S63SV
PACK4000 943183100210S TUNER,FM KST-MW104FV1-S63V 2113E2
CNVMW104FV1-
S63V
943183100220S TUNER,NORDS,FM(PALTYPE) 2113E1C CNVMW004FV1-S63
FC4140A nsp HOLDER,FUSE CLIP G645000050010S
FC4140B nsp HOLDER,FUSE CLIP G645000050010S
z
T4140 963102100020S TRANS,SWITCHING EER2834 E060283405520S
TR4140 963222500150D SEMI,FET CHIP KMB2D0N60SA J543206005510S
FC4141A nsp HOLDER,FUSE CLIP G645000050010S
FC4141B nsp HOLDER,FUSE CLIP G645000050010S
TR4142 963213500170D SEMI,TR/GE NPN 2SC KTC3198G J5023198G0000S
