Denon AVR-2113CI Service Manual

221
Ref. No. Part No. Part Name Remarks Q'ty New
N3405 nsp CN.WAFER 5P 20010-05 L101200100510S
N3406 nsp CN,WAFER C125Z2-07 7P L109012520720S
N3407 nsp CN,WAFER C125Z2-23 23P L109012522320S
N3408 nsp CN.FPC 40P 10022HS-40C L130100220400S
N3601 nsp CN.WAFER 5P SMW250-5P L102050010040S
U1001 236810057606S IC LOGIC ADV3002BSTZ J040300205510S
U1201 nsp IC,LOGIC AD8195 J040819505510S
U1301 943239100760S IC,LOGIC TC74VHC4051AFT TOSHIBA J040744051360S
U1302 963236101220D IC,LOGIC ADV7850 HDMI 1.4A J040785005510S
U1303 00D2623436907 IC,LOGIC TC74VHC244FT J040742445530S
U1601 943236101150S IC,LOGIC-ENCODER ADV8002-4 1913E3 J045800204010S
U1601 963236101320S IC,LOGIC-ENCODER ADV8003-3
2113CIE3, 2113E2,
2113E1C
J045800303010S
U1602 963248100710S
IC MEMORY FLASH (MX25L6406EM2I-
12G)
J005256401210S
U1801 nsp IC,MEMORY-RAM K4T51163QJ-BCE7 J001451163370S
U1802 nsp IC,MEMORY-RAM K4T51163QJ-BCE7 J001451163370S
U2001 nsp IC ANALOG ADSP21487KSWZ-3B3017 J080214875520S
U2002 943246012690S IC MEMORY-RAM(W9864G6JH-6) J001986466010S
U2003 963248101700S MX29LV160DBTI-70G 8952400000240
j
U2201 00D9630237503 MODULE JSR1165-C 2113E2 E100116500040S
U2203 236810062608S IC LC89058W-E J046890580020S
U2203 236810062608S IC,LOGIC-INTERFACE LC89058WA-E 2113E2 J046890580030S
U2204 00D2623077900 IC TC74VHCU04FT J040740405580S
U2205 943236100020S IC EPM3032A-TC44 J003303205510S
U2206 00D2623437906 IC TC74VHCT244AFT J040742445540S
U2207 963239002150S IC SN74LVC244APWR J040742440230S
U2401 943239100690S IC,LOGIC-D/A CONVER PCM5100 J042510005510S
U2402 231310009508S IC PQ033DNA1ZPH J126033010010S
U2403 236810086505S IC AK5358BET-E2 J043535805520S
U2404 236810073509S IC AK4358VQ-L J042435800010S
U2406 00D2631289900 IC AZ4580M J121458000020S
U2406 963239002480S IC NJM4565MD 2113E2 J121456500040S
U2407 00D2631289900 IC AZ4580M J121458000020S
U2408 00D2631289900 IC AZ4580M J121458000020S
U2409 00D2631289900 IC AZ4580M J121458000020S
U2602 nsp IC,ANALOG DM860A NETWORKED J080860A05510S
U2603 nsp IC MEMORY FLASH (H27U1G8F2BTR) J005270820020S
U2604 963246100740D IC, MEMORY-RAM A3V56S30FTP-G6 J001030563060S
U2605 963246100740D IC, MEMORY-RAM A3V56S30FTP-G6 J001030563060S
U2802 nsp IC,LINEAR-DRIVER LAN8720A J127872005510S
U2803 00D2623711004 IC LOGIC SAA7121H J045712100010S
U2805 nsp IC,LOGIC-DECODER MFI337S3959 J044337395910S
U2806 nsp IC,LINEAR-DRIVER NCP380HMU J127380150010S
U3002 943243100930S
IC CPU MICRO PROCESS
(R5F56108VNFP)
8952191300020
U3003 943239100720S
IC,MEMORY-EEPROM
R1EX24256BSAS0A
J000242565570S
U3202 00D2623437906 IC TC74VHCT244AFT J040742445540S
U3203 00D2623444902 IC TC74VHC08FT
2113CIE3, 2113E2,
2113E1C
J040740800280S
U3601 nsp IC EX3AV J048030030010S
U3602 nsp IC EX3AV J048030030010S
U3603 nsp IC EX3AV J048030030010S
U3604 nsp IC EX3AV J048030030010S
U3605 nsp IC EX3AV J048030030010S
U3607 231310009508S IC PQ033DNA1ZPH J126033010010S
NOTE :
When update Firmware,
please conrm a last
version in SDI.
Use the service board
after updating it.
NOTE :
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
