129
Remote control unit
Inserting the batteries
q Slide the rear lid in the
direction of the arrow and
remove it.
w Load the two batteries properly
as indicated by the marks in
the battery compartment.
R6/AA
e Put the rear cover back on.
NOTE
•Insert the specified batteries in the remote control unit.
•Replace the batteries with new ones if the set does not operate
even when the remote control unit is operated close to the unit. (The
supplied batteries are only for verifying operation.)
•When inserting the batteries, be sure to do so in the proper direction,
following the q and w marks in the battery compartment.
•To prevent damage or leakage of battery fluid:
•Do not use a new battery together with an old one.
•Do not use two different types of batteries.
•Do not attempt to charge dry batteries.
•Do not short-circuit, disassemble, heat or dispose of batteries in
flames.
•Do not keep the battery in a place exposed to direct sunlight or in
places with extremely high temperatures, such as near a heater.
•If the battery fluid should leak, carefully wipe the fluid off the inside
of the battery compartment and insert new batteries.
•Remove the batteries from the remote control unit if it will not be in
use for long periods.
•Used batteries should be disposed of in accordance with the local
regulations regarding battery disposal.
•The remote control unit may function improperly if rechargeable
batteries are used.
Operating range of the remote control unit
Point the remote control unit at the remote sensor when operating it.
30°30°
Approx. 23 ft/7 m
NOTE
•The set may function improperly or the remote control unit may not
operate if the remote control sensor is exposed to direct sunlight,
strong artificial light from an inverter type fluorescent lamp or
infrared light.
•When using 3D video devices that transmit radio communication
signals (such as infrared signals etc) between the various units (such
as the monitor, 3D glasses, 3D transmitter unit etc), the remote
control unit may not operate due to interference from those radio
communication signals. If this occurs, adjust the direction and
distance of the 3D communication for each unit, and check that the
remote control unit operation is not affected by these signals.
Basic version
Advanced version
InformationInformation

Table of Contents

Other manuals for Denon AVR-2312

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-2312 and is the answer not in the manual?

Denon AVR-2312 Specifications

General IconGeneral
Impedance8 Ω
Speaker selectorA+B
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels7.1 channels
Audio A/D Converter (ADC)24-bit/96kHz
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@8 Ohm)135 W
Power output per channel (20-20KHz@8 Ohm)105 W
HDMI in7
Composite video in4
Ethernet LAN (RJ-45) ports1
Multichannel audio input typeRCA
Component video (YPbPr/YCbCr) in2
Headphone connectivity6.3 mm
Connectivity technologyWired
Speakers connectivity typeBinding post
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity56
Internet radio services supportedLast.fm, Napster
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
DisplayVFD
HDMI version1.4a
Product colorBlack
Audio decodersDolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume controlRotary
Apple docking compatibilityiPad, iPhone, iPod
Number of products included1 pc(s)
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)600 W
Weight and Dimensions IconWeight and Dimensions
Depth382 mm
Width434 mm
Height167 mm
Weight11000 g
