37
Playing a network audio
Listening to internet radio
1
Prepare for playback.
q Check the network environment, then turn on this unit’s
power (vpage17 “Connecting to a home network
(LAN)”).
w If settings are required, make the “Network Connecting”
(vpage108).
2
Press NET/USB to switch the
input source to “NET/USB”.
3
Press ui to select “Internet
Radio”, then press ENTER or p.
•Selecting in the “SOURCE SELECT”
menu, lets you directly select “Internet
Radio”.
4
Press ui to select the item you
want to play, then press ENTER
or p.
5
Repeat step 4 until the station list is displayed.
The station list is displayed.
6
Press ui to select the station, then press ENTER or
p.
Playback starts once buffering reaches “100%”.
•There are many Internet radio stations on the Internet, and the
quality of the programs they broadcast as well as the bit rate of the
tracks varies widely.
Generally, the higher the bit rate, the higher the sound quality, but
depending on the communication lines and server traffic, the music
or audio signals being streamed may be interrupted. Inversely, lower
bit rates mean a lower sound quality but less tendency for the sound
to be interrupted.
•“Server Full” or “Connection Down” is displayed if the station is
busy or not broadcasting.
•On this unit, folder and file names can be displayed as titles. Any
characters that cannot be displayed are replaced with “.” (period).
•To play back compressed audio with extended bass or treble
reproduction, we recommend playback in RESTORER mode
(vpage99). The default setting is “Mode3”.
•You can specify the duration of the on-screen display to be displayed
(default: 30 sec) at menu “NET/USB” (vpage114). Press uio
p to return to the original screen.
•When STATUS on the main unit is pressed, the display can be
switched between the title name and radio station name.
nPlaying the last played Internet radio station
Simply press INTERNET RADIO V on the main unit to switch
the input source to “Internet Radio” and play the last played radio
station.
Press INTERNET RADIO V.
The source switches to “Internet Radio” and
the last played radio station plays.
•If INTERNET RADIO V on the main unit is pressed, the same
function as with the remote control unit can be obtained.
•When INTERNET RADIO V is pressed, the AMP-operation mode
starts automatically (vpage118).
nRecently played internet radio stations
Recently played internet radio stations can be selected from
“Recently Played”.
Up to 20 stations stored in “Recently Played”.
1
Press ui to select “Recently
Played”, then press ENTER or p.
2
Press ui to select the item you
want to play, then press ENTER
or p.
Basic version
Advanced version
Information
Basic version
vSee overleaf
BD

Table of Contents

Other manuals for Denon AVR-2312

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-2312 and is the answer not in the manual?

Denon AVR-2312 Specifications

General IconGeneral
Impedance8 Ω
Speaker selectorA+B
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels7.1 channels
Audio A/D Converter (ADC)24-bit/96kHz
Signal-to-Noise Ratio (SNR)100 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@8 Ohm)135 W
Power output per channel (20-20KHz@8 Ohm)105 W
HDMI in7
Composite video in4
Ethernet LAN (RJ-45) ports1
Multichannel audio input typeRCA
Component video (YPbPr/YCbCr) in2
Headphone connectivity6.3 mm
Connectivity technologyWired
Speakers connectivity typeBinding post
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
AM band range522 - 1611 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Preset stations quantity56
Internet radio services supportedLast.fm, Napster
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
DisplayVFD
HDMI version1.4a
Product colorBlack
Audio decodersDolby Pro Logic IIz, Dolby TrueHD, DTS-HD Master Audio
Volume controlRotary
Apple docking compatibilityiPad, iPhone, iPod
Number of products included1 pc(s)
AC input voltage230 V
AC input frequency50 Hz
Power consumption (standby)0.1 W
Power consumption (typical)600 W
Weight and Dimensions IconWeight and Dimensions
Depth382 mm
Width434 mm
Height167 mm
Weight11000 g
