Rear panel
See the page indicated in parentheses ( ).
q w r yt
uQ3 i
oQ0Q2 Q1
e
q FM antenna terminal (ANTENNA) ········································· (21)
w Analog audio connectors
(AUDIO) ···························································· (14, 15, 16, 18, 20)
e PRE OUT connectors
·················································· (79, 80, 81, 82, 83, 84, 85, 86, 95)
r Speaker terminals
(SPEAKERS) ··································· (79, 80, 81, 82, 83, 84, 85, 86)
t Component video connectors
(COMPONENT VIDEO) ······························ (13, 14, 15, 16, 17, 18)
y AC inlet (AC IN) ········································································ (24)
u HDMI connectors ································································· (9, 10)
i Digital audio connectors
(DIGITAL AUDIO) ································· (13, 14, 15, 16, 17, 18, 20)
o Network connector (NETWORK) ··········································· (23)
Q0 REMOTE CONTROL jacks ······················································· (22)
Q1 Video connectors (VIDEO) ···································· (13, 14, 15, 18)
Q2 TRIGGER OUT jack ·································································· (22)
Q3 RS-232C connector ·································································· (22)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
