Denon AVR-2803 Control Protocol

- 10 -
EVENT(or RESPONSE) and PARAMETER list
EVENT PARAMETER function example *RES.
PW ON POWER ON/STANDBY change PWON<CR>
STANDBY PWSTANDBY<CR>
MV ** MASTER VOLUME change , **:00 to 99 by ASCII MV80<CR>
98 = +18dB(MAX) MV795<CR>
80 = 0dB
00 = -80dB
99 = --- (MIN)
CV FL ** CHANNEL VOLUME change , **:38 to 62 by ASCII CVFL 50<CR>
FR ** 62 = +12dB(MAX) CVFR 50<CR>
C ** 50 = 0dB CVC 50<CR>
SW ** 38 = -12dB(MIN) CVSW 50<CR>
SL ** 00 = OFF (define ONLY SWch) CVSL 50<CR>
SR ** CVSR 50<CR>
SBL ** (at SBch 2SP) CVSBL 50<CR>
SBR ** (at SBch 2SP) CVSBR 50<CR>
SB ** (at SBch 1SP) CVSB 50<CR>
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO INPUT source change SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS/SAT ---Select DBS function at AVR-2803 SIDBS/SAT<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 ---Invalid at AVR-2803 SIVCR-3<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE1 ---Select CDR/TAPE function at AVR-2803 SICDR/TAPE1<CR>
MD/TAPE2 ---Invalid at AVR-2803 SIMD/TAPE2<CR>
The PARAMETER of MV, CV EVENT : Uses two or three ASCII characters. (see page4 J) section)
*RES. : NOT returns '*' parameters as RESPONSE.

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
