Denon AVR-2803 Control Protocol

- 11 -
EVENT PARAMETER function example *RES.
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
Z1 PHONO MULTI ZONE-1 source change Z1PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. Z1CDR/TAPE1<CR>
SOURCE MULTI ZONE-1 mode cancel Z1SOURCE<CR>
** MULTI ZONE-1 VOLUME change , **:00 to 99 by ASCII Z180<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
ON MULTI ZONE-1 ON/OFF change Z1ON<CR>
OFF Z1OFF<CR>
---means MULTI ZONE functions at AVR-2803
Z2 PHONO MULTI ZONE-2 source change Z2PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. Z2CDR/TAPE1<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
** MULTI ZONE-2 VOLUME change , **:00 to 99 by ASCII Z280<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
---Invalid at AVR-2803
SR PHONO REC SELECT source change SRPHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. SRCDR/TAPE1<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>
The PARAMETER of Z1, Z2 EVENT : Uses two or three ASCII characters. (see page4 J) section)

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
