Denon AVR-2803 Control Protocol

- 6 -
COMMAND PARAMETER function example
CV SB UP ---SURROUND BACKch (SBch 1SP) CVSB UP<CR>
SB DOWN CVSB DOWN<CR>
SB ** **:38 to 62 by ASCII , 50=0dB CVSB 50<CR> *
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO Select INPUT source SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS/SAT ---Select DBS function at AVR-2803 SIDBS/SAT<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 ---Invalid at AVR-2803 SIVCR-3<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE1 ---Select CDR/TAPE function at AVR-2803 SICDR/TAPE1<CR>
MD/TAPE2 ---Invalid at AVR-2803 SIMD/TAPE2<CR>
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
Z1 PHONO MULTI ZONE-1 mode set , and select source Z1PHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. Z1CDR/TAPE1<CR>
SOURCE MULTI ZONE-1 mode cancel Z1SOURCE<CR>
UP MULTI ZONE-1 VOLUME UP/DOWN , direct change to ***dB Z1UP<CR>
DOWN Z1DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB Z180<CR> *
ON MULTI ZONE-1 ON/OFF change Z1ON<CR>
OFF Z1OFF<CR>
---Set ZONE-2 functions at AVR-2803
CV , Z1 COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
