Denon AVR-2803 Control Protocol

- 7 -
COMMAND PARAMETER function example
Z2 PHONO MULTI ZONE-2 mode set , and select source Z2PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z2MD/TAPE2<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
UP MULTI ZONE-2 VOLUME UP/DOWN , direct change to ***dB Z2UP<CR>
DOWN Z2DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB Z280<CR> *
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
---Invalid at AVR-2803
SR PHONO REC SELECT mode set , and select source SRPHONO<CR>
| ---The name of PARAMETER is |
CDR/TAPE1 the same as that of the time of SI COMMAND. SRCDR/TAPE1<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>
SV DVD VIDEO SELECT mode set , and select source SVDVD<CR>
VDP SVVDP<CR>
TV SVTV<CR>
DBS/SAT SVDBS/SAT<CR>
VCR-1 SVVCR-1<CR>
VCR-2 SVVCR-2<CR>
VCR-3 ---Invalid at AVR-2803 SVVCR-3<CR>
V.AUX SVV.AUX<CR>
SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>
SD AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR>
PCM set DIGITAL INPUT force PCM mode SDPCM<CR>
DTS set DIGITAL INPUT force DTS mode SDDTS<CR>
RF ---Invalid at AVR-2803 SDRF<CR>
ANALOG set force ANALOG INPUT mode SDANALOG<CR>
EXT.IN-1 set EXT.IN-1 mode ---Set EXT.IN mode at AVR-2803 SDEXT.IN-1<CR>
EXT.IN-2 set EXT.IN-2 mode ---Invalid at AVR-2803 SDEXT.IN-2<CR>
Z2 COMMAND : "*" parameter uses two or three ASCII characters. (see page4 J) section)

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
