Denon AVR-2803 Service Manual

45
45
AVR-2803/983/AVC-2870
R403-406 241 2376 964 RD14B2E470JNBST
R407-414 244 2671 956 RS14B3DR47JNBST(S)
R425,426 244 2682 903 RS14B3D010JNBST(S) *
R427,428 244 2671 901 RS14B3D100JNBST(S)
R501 241 2387 940 RD14B2E4R7JNBST
R502 244 2051 961 RS14B3A101JNBST(S)
R503,504 243 2039 032 RW99=3H0R1K
! R524 242 2009 001 RC05GF2H225K(UL) for EU,EC
R527,528 244 2052 960 RS14B3A221JNBST(S)
R531 245 2367 920 RN14K2E152FT(5)
R534,535 244 2052 960 RS14B3A221JNBST(S)
VR101,102 211 6131 939 V06PB331T
VR201 211 6131 939 V06PB331T
VR301,302 211 6131 939 V06PB331T
VR401,402 211 6131 939 V06PB331T
CAPACITORS GROUP
C101,102 254 4527 982 CE04W2A100MT SMG/RE3
C103-106 254 4586 936 CE04W2A4R7MT(RE3)
C107,108 256 1058 939 CF93A1H473JT (JL)
C109,110 255 1264 982 CQ93M1H472JT(B)
C111,112 257 0509 929 CK73B1H102KT
C201 254 4527 982 CE04W2A100MT SMG/RE3
C203 254 4586 936 CE04W2A4R7MT(RE3)
C205 254 4586 936 CE04W2A4R7MT(RE3)
C207 256 1058 939 CF93A1H473JT (JL)
C209 255 1264 982 CQ93M1H472JT(B)
C212 257 0509 929 CK73B1H102KT
C301,302 254 4527 982 CE04W2A100MT SMG/RE3
C303-306 254 4586 936 CE04W2A4R7MT(RE3)
C307,308 256 1058 939 CF93A1H473JT (JL)
C309,310 255 1264 982 CQ93M1H472JT(B)
C311,312 257 0509 929 CK73B1H102KT
C313,314 255 1264 982 CQ93M1H472JT(B)
C315,316 257 0509 929 CK73B1H102KT
C401,402 254 4527 982 CE04W2A100MT SMG/RE3
C403-406 254 4586 936 CE04W2A4R7MT(RE3)
C407,408 256 1058 939 CF93A1H473JT (JL)
C409,410 255 1264 982 CQ93M1H472JT(B)
C411,412 257 0509 929 CK73B1H102KT
C502 254 4524 943 CE04W1H010MT SMG/RE3
C503-505 256 1064 907 CF93A2E334KT(B)L=16
C506 254 4528 729 CE04W2A101MC SMG/RE3
C507,508 254 6234 707 CE68W1J123M(DL) *
C516 254 4538 900 CE04W1C100MT SMG/RE3
C517 254 4524 943 CE04W1H010MT SMG/RE3
C522 254 4403 721 CE04W1E222MC (SMG)
C523 254 4524 943 CE04W1H010MT SMG/RE3
C524 256 1058 971 CF93A1H104JT (JL)
C528 253 1181 904 CK45F1H103ZT(DD-3)
C529,530 255 1264 908 CQ93M1H102JT(B)
C531 256 1058 971 CF93A1H104JT (JL)
C599 254 4524 943 CE04W1H010MT SMG/RE3
C601-604 257 0512 903 CK73F1E104ZT
C615 254 4524 943 CE04W1H010MT SMG/RE3
C616-635 254 4538 913 CE04W1C220MT SMG/RE3
C636 257 0512 903 CK73F1E104ZT
C637 254 4524 943 CE04W1H010MT SMG/RE3
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
