Denon AVR-2803 Service Manual

48
48
AVR-2803/983/AVC-2870
RESISTORS GROUP
R586 244 2052 960 RS14B3A221JNBST(S)
R932 241 2387 908 RD14B2E010JNBST
R934 244 2055 996 RS14B3A122JNBST(S)
R939,940 244 2055 996 RS14B3A122JNBST(S)
CAPACITORS GROUP
C214,215 257 0511 904 CK73F1H103ZT
C251-254 257 0511 904 CK73F1H103ZT
C256 257 0512 903 CK73F1E104ZT
C259,260 254 4538 939 CE04W1C470MT SMG/RE3
C261,262 257 0511 904 CK73F1H103ZT
C263 254 4302 974 CE04W1A101MT(SRE)
C264 257 0512 903 CK73F1E104ZT
C265 254 4538 939 CE04W1C470MT SMG/RE3
C266 257 0512 903 CK73F1E104ZT
C267 254 4538 939 CE04W1C470MT SMG/RE3
C268,269 257 0512 903 CK73F1E104ZT
C271,272 257 0512 903 CK73F1E104ZT
C273 254 4524 943 CE04W1H010MT SMG/RE3
C274-276 257 0512 903 CK73F1E104ZT
C277,278 257 0511 904 CK73F1H103ZT
C280 254 4302 974 CE04W1A101MT(SRE)
C401-403 257 0512 903 CK73F1E104ZT
C404 254 4524 943 CE04W1H010MT SMG/RE3
C405-412 257 0512 903 CK73F1E104ZT
C451,452 257 0516 954 CK73B1E104KT
C453,454 254 4538 939 CE04W1C470MT SMG/RE3
C455 254 4533 921 CE04W0J101MT SMG/RE3
C457 257 0504 940 CC73CH1H330JT
C458 257 0501 901 CK73B1H103KT (1608)
C459,460 257 0503 925 CC73CH1H100DT
C461 255 1265 978 CQ93M1H223JT(B)
C462 254 4524 972 CE04W1H4R7MT SMG/RE3
C463 257 0506 951 CC73CH1H101JT
C464 254 4524 943 CE04W1H010MT SMG/RE3
C465 254 4538 900 CE04W1C100MT SMG/RE3
C466 255 1264 908 CQ93M1H102JT(B)
C467 254 4536 928 CE04W1A101MT SMG/RE3
C468 257 0511 904 CK73F1H103ZT
C469 255 1264 911 CQ93M1H122JT(B)
C470 257 0506 993 CC73CH1H151JT
C471 254 4524 943 CE04W1H010MT SMG/RE3
C472 256 1058 955 CF93A1H683JT (JL)
C473 257 0508 917 CC73CH1H471JT
C474 257 0510 918 CK73B1H332KT
C486,487 257 0504 940 CC73CH1H330JT
C488 254 4536 928 CE04W1A101MT SMG/RE3
C489 257 0511 904 CK73F1H103ZT
C490 254 4538 900 CE04W1C100MT SMG/RE3
C503,504 254 4538 939 CE04W1C470MT SMG/RE3
C505-512 257 0511 904 CK73F1H103ZT
C513,514 254 4536 928 CE04W1A101MT SMG/RE3
C517,518 254 4538 939 CE04W1C470MT SMG/RE3
C521-524 257 0511 904 CK73F1H103ZT
C529,530 254 4536 928 CE04W1A101MT SMG/RE3
C532,533 256 1058 939 CF93A1H473JT (JL)
C534 254 4524 943 CE04W1H010MT SMG/RE3
C535 256 1058 939 CF93A1H473JT (JL)
C536-539 257 0512 903 CK73F1E104ZT
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
