Denon AVR-2803 Service Manual

50
50
AVR-2803/983/AVC-2870
JK404 205 0902 004 1P S-TERMINAL(SW)
JK406-408 204 8654 005 3P PIN JACK (S2GND)
JK701,702 204 8260 004 MINI JACK
JK703 204 8649 007 MINI JACK (RD)
JK704 204 8657 002 MINI JACK
L451 235 0060 963 INDUCTOR(150)ST
RL401-404 214 0223 004 RELAY(EC2-24N35)
S201 212 0373 000 ROT.ENCODER-EC16B
S202-205 212 5611 903 TACT SWITCH(TAPE H5)
S401 212 0408 001 SLIDE SWITCH for E1,E1H
TP601 205 0154 030 3P NH CONNECTOR BASE
W701,702 205 1034 007 M3 SCREW TERMINAL
W708,709 205 1034 010 M3 SCREW TERMINAL
X451 399 0739 006 X'TAL(14.32M-RIBER)
X452 399 0105 009 CSB503F2
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
