Denon AVR-2803 Service Manual

52
52
AVR-2803/983/AVC-2870
CAPACITORS GROUP
C102 257 0512 903 CK73F1E104ZT
C103,104 254 4193 905 CE04W1C100MT (SRA)
C107 256 1058 971 CF93A1H104JT (JL)
C109 254 4196 999 CE04W1H220MT (SRA)
C110-113 257 0511 904 CK73F1H103ZT
C115 257 0511 904 CK73F1H103ZT
C117 257 0509 929 CK73B1H102KT
C120 257 0504 937 CC73CH1H300JT
C121 254 4193 905 CE04W1C100MT (SRA)
C122 257 0511 917 CK73F1H223ZT
C125 257 0511 904 CK73F1H103ZT
C126 257 0509 929 CK73B1H102KT
C504 257 0516 954 CK73B1E104KT
C505 254 4524 943 CE04W1H010MT SMG/RE3
C508 257 0506 951 CC73CH1H101JT
C509 257 0511 904 CK73F1H103ZT
C515 254 4538 939 CE04W1C470MT SMG/RE3
C516 257 0511 904 CK73F1H103ZT
C520 257 0516 954 CK73B1E104KT
C531 257 0511 904 CK73F1H103ZT
C537 254 4536 957 CE04W1A471MT SMG/RE3
C539,540 254 4533 921 CE04W0J101MT SMG/RE3
C542 257 0509 929 CK73B1H102KT
C543 257 0516 954 CK73B1E104KT
C545 257 0509 929 CK73B1H102KT
C546 254 4533 934 CE04W0J221MT SMG/RE3
C547,548 257 0503 967 CC73CH1H150JT
C549 257 0509 929 CK73B1H102KT
C550 257 0516 954 CK73B1E104KT
C551,552 257 0509 929 CK73B1H102KT
C553 257 0516 954 CK73B1E104KT
C554 254 4534 713 CE04W0J332MC SMG/RE3 for EU,EC
C554 259 0007 702 SB CAP==822=C for E2,E1,E1C,E1H,EUT,E1K
C555 257 0511 904 CK73F1H103ZT
C557 257 0509 929 CK73B1H102KT
C558 257 0516 954 CK73B1E104KT
C559,560 257 0509 929 CK73B1H102KT
C561,562 257 0516 954 CK73B1E104KT
C564 257 0512 903 CK73F1E104ZT
C565,566 257 0516 954 CK73B1E104KT
C568,569 257 0509 929 CK73B1H102KT
C570 254 4368 934 CE04W1E101MT(ASF)
C571 257 0512 903 CK73F1E104ZT
C574 257 0511 904 CK73F1H103ZT
C575 254 4522 903 CE04W1V4R7MT SMG/RE3
C576 257 0512 903 CK73F1E104ZT
C581 256 1058 984 CF93A1H124JT (JL)
C591 257 0509 929 CK73B1H102KT
C593 257 0509 929 CK73B1H102KT
C611-614 257 0512 903 CK73F1E104ZT
C701 257 0509 929 CK73B1H102KT
C702 257 0511 920 CK73F1H473ZT
C703-706 257 0509 929 CK73B1H102KT
C709 257 0506 951 CC73CH1H101JT
C712 254 4538 900 CE04W1C100MT SMG/RE3
C713-715 254 4524 943 CE04W1H010MT SMG/RE3
C801 257 0507 976 CC73CH1H331JT for E2
C802 254 4524 943 CE04W1H010MT SMG/RE3 for E2
C803 254 4538 900 CE04W1C100MT SMG/RE3 for E2
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
