Denon AVR-2803 Service Manual

72
72
AVR-2803/983/AVC-2870
C127 254 4313 950 CE04W1H101MT(ASF)
C531 257 0511 904 CK73F1H103ZT
C537 254 4480 906 CE04W0J331MT(ASF)
C539,540 254 4533 921 CE04W0J101MT SMG/RE3
C545 257 0509 929 CK73B1H102KT
C546 254 4480 906 CE04W0J331MT(ASF)
C547,548 257 0503 967 CC73CH1H150JT
C549 257 0509 929 CK73B1H102KT
C550 257 0516 954 CK73B1E104KT
C551,552 257 0509 929 CK73B1H102KT
C553 257 0516 954 CK73B1E104KT
C554 254 4534 713 CE04W0J332MC SMG/RE3
C555 257 0511 904 CK73F1H103ZT
C557 257 0509 929 CK73B1H102KT
C558 257 0516 954 CK73B1E104KT
C559 257 0509 929 CK73B1H102KT
C561 257 0516 954 CK73B1E104KT
C564 257 0512 903 CK73F1E104ZT
C565 257 0516 954 CK73B1E104KT
C568 257 0509 929 CK73B1H102KT
C570 254 4368 934 CE04W1E101MT(ASF)
C571 257 0512 903 CK73F1E104ZT
C574 257 0511 904 CK73F1H103ZT
C575 254 4522 903 CE04W1V4R7MT SMG/RE3
C576 257 0512 903 CK73F1E104ZT
C581 256 1058 984 CF93A1H124JT (JL)
OTHER PARTS GROUP
CW073 205 1000 015 7P FJ CONN.PLUG
CW141,142 205 1165 002 14P CON PLUG TMC-D
CX035 205 1121 033 3P CON.BASE-L(5268)
CX042 205 0884 083 4P CON.BASE(TUC-P)
CX048 205 0884 083 4P CON.BASE(TUC-P)
CX061 205 0943 018 6P CON.BASE(TUC-P)
CX076,077 205 0943 021 7P CON.BASE(TUC-P)
CX083 205 0884 096 8P CON BASE(TUC-P)
CX091 205 0884 038 9P CON.BASE TUC-P
CX095 205 0884 038 9P CON.BASE TUC-P
CX102 205 0884 054 10P CON.BASE TUC-P
CX104 205 0884 054 10P CON.BASE TUC-P
CX112 205 0884 067 11P CON.BASE TUC-P
CX133 205 1091 037 13P CON BASE TWG-P
CX141,142 205 1164 003 14P CON SOCKET TMC-D
CX151 205 0884 041 15P CON.BASE TUC-P
CX154 205 1249 054 15P JE CON.BASE
CX157 205 0884 041 15P CON.BASE TUC-P
CX191,192 205 1091 008 19P CON.BASE(TWG-P)
CX952 205 0884 041 15P CON.BASE TUC-P
FB101 244 2050 904 RS14B3A220JNBST(S)
FB502 247 0018 905 RM73B--0R0KT
FB503,504 235 0147 909 E.FIL(BLM21PG221SN1)
FB507 235 0049 900 BEADS INDUCTOR TAPE
FB509 235 0049 900 BEADS INDUCTOR TAPE
FB511 235 0049 900 BEADS INDUCTOR TAPE
FL101 393 8033 007 FLD(CM1690C)
S101-112 212 5611 903 TACT SWITCH(TAPE H5)
Ref.No. Part No. Part Name Remarks New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
