Denon AVR-2803 Service Manual

86
86
AVR-2803/983/AVC-2870
10 412 4210 002 BRACKET 2
11 412 4716 014 SUPPORT BRACKET 1
12 104 0194 289 FOOT ASS'Y for EU,EC,E2,E1,E1C,E1H,EUT,E1K 4
12 104 0173 213 FOOT ASS'Y for JP 4
13 412 3548 005 P.W.B CATCHER 3
14 412 2814 028 CARD SPACER(L=10) 4
! 15 206 2160 009 AC CORD VH N/I E3 for EU,EC,EUT 1
! 15 206 2089 106 AC CORD W/CON.E2 for E2 1
! 15 206 2175 007 AC CORD(E1/VH) for E1 1
! 15 206 2174 008 AC CORD(E1C/VH) for E1C 1
! 15 206 2177 005 AC CORD(EK/VH) for E1H 1
! 15 206 2178 004 KOREA AC CORD VH for E1K 1
16 412 5025 005 SIDE BRACKET for E2,E1,E1C,E1H, E1K 1
17 412 2814 028 CARD SPACER(L=10) for EU,EC,E2,E1C,EUT,E1K,JP 10
17 412 2814 028 CARD SPACER(L=10) for E1,E1H 11
18 461 0573 062 RUBBER SHEET 1
21 412 2814 031 CARD SPACER (L=4) 1
22 412 2814 099 CARD SPACER (L=2.5) 1
25 414 0979 000 SHIELD PLATE (B) 1
26 409 0052 019 HOLDER (A) 1
27 412 2404 069 PWB HOLDER (WLS-12) 1
28 461 0639 003 RUBBER SHEET 1
 29 203 2374 090 2P VA-VA CABLE for E2,E1,E1C,E1H,EUT,E1K 1
30 105 1428 009 BACK PANEL for AVR-2803EU,EC 1 *
30 105 1428 012 BACK PANEL for AVR-983EU 1 *
30 105 1428 025 BACK PANEL for E2 1 *
30 105 1428 038 BACK PANEL for E1,E1H 1 *
30 105 1428 041 BACK PANEL for E1C 1 *
30 105 1428 067 BACK PANEL for EUT 1 *
30 105 1428 054 BACK PANEL for E1K 1 *
30 105 1428 070 BACK PANEL for JP 1 *
31 449 0070 002 LOCKING CARD SPACER 1
32 445 0056 008 CORD BUSH for EU,EC,E2,E1,E1C,E1H,EUT,E1K 1
33 205 1116 006 TERMINAL ASS 1
34 216 0117 006 AM FM TUNER(E3) for EU,EC 1 *
34 216 0118 005 AM FM TUNER(E2) for E2 1 *
34 216 0119 004 AM FM TUNER(E1) for E1,E1C,E1H,EUT,E1K 1 *
 35 009 0151 011 15P FFC CABLE(1.25) for EU,EC,E2,E1,E1C,E1H,EUT,E1K 1
! 36 203 3983 008 AC INLET for JP 1
 37 445 8004 007 WIRE CLAMPER for EU,EC 2
 37 445 8004 007 WIRE CLAMPER for E2,E1,E1H 4
 37 445 8004 007 WIRE CLAMPER for E1C,E1H,E1K,JP 3
! 38 203 3981 000 AC OUTLET (E2) for E2,E1,E1H 1
 39 203 5298 018 3P VH CON. CORD for E2 1
 39 203 5298 021 3P VH CON.CORD(YEL) for E1,E1H 1
40 449 0133 017 PWB HOLDER for E1,E1H 2
41 146 2214 255 INNER PANEL for EU,EC 1
41 146 2214 226 INNER PANEL for E2 black model 1
41 146 2214 239 INNER PANEL for gold model 1
41A 146 2270 008 BLIND SHEET for gold model 1
42 441 0949 090 SPACER 1
43 144 2827 002 FRONT PANEL ASS'Y for AVR-2803EU,EC 1 *
43 144 2827 015 FRONT PANEL ASS'Y for AVR-983EU 1 *
43 144 2827 028 FRONT PANEL ASS'Y for E2 black model 1 *
43 144 2827 031 FRONT PANEL ASS'Y for E2 gold model 1 *
43 144 2827 044 FRONT PANEL ASS'Y for E1,E1C,E1H,EUT,E1K 1 *
43 144 2827 057 FRONT PANEL ASS'Y for JP 1 *
44 131 0158 007 DENON BADGE for black model 1
44 131 0158 010 DENON BADGE for gold model 1
45 417 0648 000 RADIATOR 1*
Ref.No. Part No. Part Name Remarks Q'ty New

Denon AVR-2803 Specifications

General

Power Output	90 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Channels	7.1
Dolby Support	Dolby Digital, Dolby Pro Logic II
Digital Inputs	2 coaxial, 3 optical
Weight	14.5 kg
Type	AV Receiver
Output Power per Channel	90 W (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Input Sensitivity	200 mV
Input Impedance	47 kOhms
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV / 47 kOhms
Tuner Frequency Range	FM: 87.5 - 108 MHz, AM: 522 - 1611 kHz
DTS Support	DTS, DTS-ES, DTS Neo:6
Outputs	Composite: 2, Component: 1
Video outputs	Composite: 2
