Denon AVR-3311 User Manual

97
ENGLISH
Basic versionSimple version Advanced version Information
97
ENGLISH
Basic versionSimple version Advanced version Information
Operating the sub remote control unit
n Tuner (HD Radio) operation
Operation buttons Function
Zone selection M Z2 Z3
ZONE SELECT Zone operation mode selection
ZONE OFF Power turned off
z2
ZONE ON Power turned on
z2
QUICK SELECT Quick select operation
INPUT SOURCE
SELECT
Input source selection
CH +, – Preset channel selection
SHIFT Preset channel block selection
VOL +, – Adjustment of volume
z2
MUTE Muting
z2
MENU Menu –
MEMORY Preset memory registration
uio p
Multicast switching (ui) /
Cursor operation
TUNING df
Tuning up/down
USB
z3
ALL MUSIC
z1
(Media server only)
z4
FAVORITES
z1
z5
z1 Whether “Music” or “Favorites” is selected depends on the
“Direct Play” setting (vpage72).
z2 Affects the currently selected zone.
z3 The input source switches to “NET/USB” and the files on the
USB memory device are played.
z4 The input source switches to “NET/USB” and the files in “Music”
on the media server are played.
z5 The input source switches to “NET/USB” and the files in
“Favorites” are played.
Switching the multi-zone input source to
the same input source as used in the MAIN
ZONE
This function is convenient for example when you want to listen to the
same song as the one playing in the MAIN ZONE while in a different
zone.
1
3UHVVZONE SELECTDQGVHWWR
=21(RU=21(
The currently selected multi-zone
indicator illuminates.
2
3UHVV M.ZONE CALL RQ WKH VXE
UHPRWHFRQWUROXQLW
The multi-zone input source switches to
the MAIN ZONE’s input source.
NOTE
• This function cannot be used for the MAIN ZONE.
• When
M.ZONE CALL is pressed while the multi-zone power is off,
the multi-zone power turns on and the input source switches to the
MAIN ZONE’s input source.
n SAT TU (SIRIUS) operation
Operation buttons Function
Zone selection M Z2 Z3
ZONE SELECT Zone operation mode selection
ZONE OFF Power turned off
z2
ZONE ON Power turned on
z2
QUICK SELECT Quick select operation
INPUT SOURCE
SELECT
Input source selection
CH +, – Preset channel selection
SHIFT Preset channel block selection
VOL +, – Adjustment of volume
z2
MUTE Muting
z2
MENU Menu –
MEMORY Preset memory registration
uio p
Category search / Cursor operation
ENTER
To Parental Lock password check
screen (press and hold)
TUNING df
Channel selection
USB
z3
ALL MUSIC
z1
(Media server only)
z4
FAVORITES
z1
z5
z1 Whether “Music” or “Favorites” is selected depends on the
“Direct Play” setting (vpage72).
z2 Affects the currently selected zone.
z3 The input source switches to “NET/USB” and the files on the
USB memory device are played.
z4 The input source switches to “NET/USB” and the files in “Music”
on the media server are played.
z5 The input source switches to “NET/USB” and the files in
“Favorites” are played.

Denon AVR-3311 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/192kHz
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Optical drive included	No
Display	LED
Equalizer	Yes
HDMI version	1.4a
Product color	Silver
Audio decoders	DTS 96/24, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD
Volume control	Rotary
Multi-Zone quantity	4
Apple docking compatibility	iPod Classic 4, iPod Classic 5, iPod Mini 1, iPod Mini 2, iPod Nano 1, iPod Nano 2
Supported video modes	1080p
HDMI in	6
Audio (L/R) in	9
Composite video in	5
USB ports quantity	1
S-Video inputs quantity	2
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
AM band range	522 - 1611 kHz
FM band range	57.5 - 108 MHz
Composite video out	3
Headphone connectivity	3.5 mm/6.35 mm
Digital audio coaxial out	0
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	381 mm
Width	434 mm
Height	171 mm
Weight	12200 g
