Page #117 background imageLoading...
Page #117 background image
114
ENGLISH
GAudioH
Symptom Cause/Solution Page
Audio is not output. Check the connections for all devices.
Check the speaker connections.
Check whether the audio device power is turned on.
Adjust the master volume.
Cancel the mute mode.
Select a suitable input source.
Select a suitable input mode.
• Disconnect the headphones. No sound is output from the speakers
or the PRE OUT connectors when headphones are connected.
5, 14 – 23
5, 50 – 52
24, 62
25, 62
24, 62
71
100
No sound is
produced from
surround speaker.
Check if the surround speakers are connected to the SURROUND
terminals.
No sound is
produced from
surround back
speaker.
Set “Amp Assign” on the menu to “Normal”.
Set “Speaker Config.” – “S.Back” on the menu to something
other than “None”.
Set “Surround Parameter” – “S.Back” on the menu to something
other than “OFF”.
Set the surround mode to something other than “STEREO”.
79
80
74
47
No sound is
produced from front
height speaker.
Set “Surround Parameter” – “F.Height” on the menu to “ON”.
Set “Amp Assign” on the menu to “Normal”.
Set “Speaker Config.” – “Surround” on the menu to something
other than “None”.
74
79
80
No sound is
produced from
subwoofer.
Check the subwoofer connections.
Turn on the subwoofer’s power.
Set “Speaker Config.” – “Subwoofer” on the menu to “Yes”.
If “Front” and “Center” for “Speaker Config.” are set to “Large”,
and “Subwoofer Mode” is set to “LFE”, no sound may be output
from the subwoofers, depending on the input signal or selected
surround mode.
5, 50 – 52
6
80
80
DTS sound is not
output.
Set “Decode Mode” on the menu to “Auto” or “DTS”. 71
Dolby TrueHD, DTS-
HD, Dolby Digital
Plus audio is not
output.
Make HDMI connections. 14
GHDMIH
Symptom Cause/Solution Page
No audio is
output with HDMI
connection.
Check the connection of the HDMI connectors.
When outputting HDMI audio from the speakers, set “HDMI
Audio Out” on the menu to “AMP”.
When outputting HDMI audio from a TV, set “HDMI Audio Out”
on the menu to “TV”.
14
82
82
No video is
output with HDMI
connection.
Check the connection of the HDMI connectors.
Set the input source to match the connected HDMI connector.
Check whether the TV is compatible with copyright protection
(HDCP). If connected to a device not compatible with HDCP, video
will not be output correctly.
14
14, 24
14
When the following
operations are
performed on
devices compatible
with HDMI control,
the same operations
occur on this unit.
• Power ON/OFF
• Switching audio
output devices
• Adjust volume
Switch input source
Set “HDMI Control” on the menu to “OFF”. To operate power
only for each device, set “Power Off Control” to “OFF”.
54, 82
GSIRIUS Satellite RadioH
Symptom Cause/Solution Page
“CHECK SIRIUS
TUNER” is displayed.
The SiriusConnect Home Tuner unit is not connected. Check that
the connections are correct.
20
”ANTENNA ERROR”
is displayed.
The antenna is not connected. Check that the connections are
correct.
20
”NO SIGNAL” is
displayed.
The antenna is not connected. Check that the connections are
correct.
”INVALID
CHANNEL” is
displayed.
Channel is not present. Select another channel.
”ACQUIRING
SIGNAL” is
displayed.
The signal cannot be received. Reposition your SiriusConnect
Home Tuner and Home Dock antenna.
Displays while SiriusConnect Home Tuner is connected. Reposition
your SiriusConnect Home Tuner and Home Dock antenna.
”Call SIRIUS”
z
is
displayed.
Channels are not subscribed to. If you subscribe to the channel,
you can receive the channel.
”SUBSCRIPTION
UPDATED” is
displayed.
While updating contract information.
”Enter Lock Code
[ ]” is displayed.
Selected channels are locked. Please insert pass word (4 digits)
into “[ ]”
z After scroll displays “Call 888-539-....” twice, displays “Call SIRIUS”.
