102
ENGLISH
Rear panel
See the page indicated in parentheses ( ).
i
q w
e r yt u
Q0
o
Q6 Q5 Q4Q3 Q2 Q1
q RS-232C connector ·································································· (23)
w HD Radio antenna terminals ·················································· (20)
e Analog audio connectors ·····································(16 – 18, 21, 23)
r PRE OUT connectors ··············································(5, 23, 50 – 52)
t SIGNAL GND terminal ···························································· (21)
y Speaker terminals ························································(5, 50 – 52)
u AC inlet (AC IN) ·········································································· (5)
i HDMI connectors ····································································· (14)
o COMPONENT VIDEO connectors ····································· (16, 17)
Q0 Digital audio connectors ··················································(16 – 18)
Q1 ETHERNET connector ····························································· (22)
Q2 REMOTE CONTROL jacks ······················································· (23)
Q3 DOCK CONTROL jack ······························································ (19)
Q4 S-VIDEO/VIDEO connectors ············································(16 – 19)
Q5 SIRIUS connector ···································································· (20)
Q6 TRIGGER OUT jacks ································································ (23)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
