Manual Setup
Default settings are underlined.
Perform when setting the speakers manually or when changing settings made in Audyssey
®
Setup.
•If you change the speaker settings after performing Audyssey
®
Setup, it will not be possible to select
Audyssey MultEQ
®
XT, Audyssey Dynamic EQ
®
and Audyssey Dynamic Volume
®
(vpage116).
•“Manual Setup” can be used without changing the settings. Please set if necessary.
Setting items Setting details
Amp Assign
Select power amplifier
usage method to match
your speaker system.
Assign Mode : Set the assignment mode.
•Main Only : Setting for 7.1-channel playback using surround back, front
height, or front wide speakers.
•ZONE2 : Setting to assign the unit’s built-in power amplifier for ZONE2
and output the audio in stereo.
•ZONE3 : Setting to assign the unit’s built-in power amplifier for ZONE3
and output the audio in stereo.
•Z2/Z3(M) : Setting to assign the unit’s built-in power amplifier for ZONE2
and ZONE3 and output the audio in monaural.
•Bi-AMP : Setting to use the front speakers via the bi-amp connection.
•Front B : Setting to use the second set of front speakers for playback.
You can switch the front speakers A and B to be used for playback in
accordance with the 2-channel playback or multi-channel playback mode.
When you select this Front B setting, also perform the “Front Speaker
Setup” (vpage133) procedure.
•2CH : Setting to use the other front speakers for playback when you do
2-channel playback in DIRECT or STEREO mode.
NOTE
The HDMI audio signals for the input source selected in ZONE2 are not
output from the ZONE2 speakers.
Setting items Setting details
Speaker Config.
Indicate speaker presence
and select speaker size
categories based on bass
reproduction capability.
NOTE
Do not use the outward
shape of the speaker to
determine selection of a
“Large” or “Small” speaker.
Instead, use the frequencies
set in “Crossovers”
(vpage133) as the
standard for determining
bass reproduction capability.
Front : Set the front speaker size.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•When “Subwoofer” is set to “No”, “Front” is automatically set to
“Large”.
•When “Front” is set to “Small”, “Center”, “Surround“, “Surr.Back”,
“Front Height” and “Front Wide” can not be set to “Large”.
Center : Set the presence and size of the center speaker.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•None : Select when a center speaker is not connected.
“Large” is not displayed when “Front” is set to “Small”.
Subwoofer : Set the presence of a subwoofer.
•Yes : Use a subwoofer.
•No : Select when a subwoofer is not connected.
When “Front” is set to “Small”, “Subwoofer” is automatically set to
“Yes”.
Surround : Set the presence and size of the surround speakers.
•Large : Use a large speaker that can adequately play back low
frequencies.
•Small : Use a small speaker that has inadequate playback capacity for
low frequencies.
•None : Select when the surround speakers are not connected.
•When “Surround” is set to “Large”, “Surr.Back”, “Front Height” and
“Front Wide” can be set to “Large”.
•When “Surround” is set to “None”, “Surr.Back”, “Front Height” and
“Front Wide” are automatically set to “None”.
Speakers
Basic version
Advanced version
Informations
Advanced version
v See overleaf
DVD

Denon AVR-3313CI Specifications

General

Receiver type	-
Audio output channels	7.1 channels
Power output per channel (1KHz@6 Ohm)	165 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	7
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
12V trigger	Yes
Audio formats supported	AAC, FLAC, MP3, WMA
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Pandora, SIRIUS Internet Radio, Spotify, vTuner
Product color	Black
Audio decoders	Dolby Digital Plus, Dolby Pro Logic IIz, Dolby TrueHD, DTS 96/24, DTS Digital Surround, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-HD, DTS-HD Master Audio
Volume control	Rotary

Weight and Dimensions

Depth	378.9 mm
Width	434.3 mm
Height	166.8 mm
Weight	11997 g
