156
Rear panel
See the page indicated in parentheses ( ).
q w yt
i
u
o
Q0
Q1Q2Q3Q4Q5
e r
q FM/AM antenna terminals (ANTENNA) ································ (24)
w Analog audio connectors
(AUDIO) ······················································ (16, 17, 18, 20, 22, 23)
e PRE OUT connectors
················································ (25, 85, 86, 87, 88, 89, 90, 91, 104)
r SIGNAL GND terminal ···························································· (23)
t Video connectors (VIDEO) ···························· (15, 16, 17, 20, 104)
y Speaker terminals
(SPEAKERS) ········································· (85, 86, 87, 88, 89, 90, 91)
u AC inlet (AC IN) ········································································ (28)
i Component video connectors
(COMPONENT VIDEO) ······························ (15, 16, 17, 18, 19, 20)
o HDMI connectors ······················································· (10, 11, 104)
Q0 Denon Link HD connector ······················································· (12)
Q1 Digital audio connectors
(DIGITAL AUDIO) ································· (15, 16, 17, 18, 19, 20, 22)
Q2 Network connector (NETWORK) ··········································· (27)
Q3 REMOTE CONTROL jacks ······················································· (26)
Q4 RS-232C connector ·································································· (26)
Q5 TRIGGER OUT jack ·································································· (26)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
