134
Speakers
Setting items Setting details
2ch Playback
(Continued)
SW Mode : Select low range signals to be reproduced by subwoofer.
•LFE : When the “2ch Playback – “Front” setting is set to “Large”, the
LFE signal alone is output from the subwoofer. Also, when the “2ch
Playback” – “Front” setting is set to “Small”, the front channel low
range signal is added to the LFE signal output from the subwoofer.
•LFE+Main : The front channel low range signal is added to the LFE signal
output from the subwoofer.
This setting can be set made “2ch Playback” – “Subwoofer” is set to
“Yes”.
Crossover : Set the maximum frequency of the bass signal output from
each channel to the subwoofer.
•40Hz / 60Hz / 80Hz / 90Hz / 100Hz / 110Hz / 120Hz / 150Hz / 200Hz /
250Hz
•This setting can be set made “2ch Playback” – “Subwoofer” is set to
“Yes”.
•If the “2ch Playback” – “Front” setting is “Large” and the “SW Mode”
setting is “LFE”, “Full Band” is displayed and the setting cannot be
made.
Distance FL / Distance FR : Select speaker for distance setting.
•0.0ft – 60.0ft (12.0ft) / 0.00m – 18.00m (3.60m) : Set distance from
main listening point to speaker.
Set the difference in the distance between the speakers to less than
20.0 ft (6.00 m).
Level FL / Level FR : Select speaker for level adjustment.
•–12.0dB – +12.0dB (0dB) : Adjust the level of each channel.
To Next Page
