Denon AVR-3805 Service Manual

65
65
AVR-3805 / AVC-3890
D602 276 0305 001 S4VB20
D603,604 276 0432 903 1SS270A TE (TAPE)
D605 276 0305 001 S4VB20
D606,607 276 0432 903 1SS270A TE (TAPE)
D608 276 0305 001 S4VB20
D609,610 276 0704 903 1SR35-400A(T93X)
D611 276 0432 903 1SS270A TE (TAPE)
D612 276 0747 902 RB441Q-40T-77
ZD601,602 276 0477 926 HZS16-3TD
ZD603 276 0474 903 HZS12B-1TD
ZD604,605 276 0463 901 HZS6C-1TD
PT601 279 0034 067 PTH9M04BB222TS2F333
RESISTORS GROUP
R127,128 241 2379 987 RD14B2E102JNBST
R133,134 241 2379 987 RD14B2E102JNBST
R137,138 244 2671 914 RS14B3D153JNBST(S)
R139,140 241 2378 920 RD14B2E221JNBST
R141,142 241 2378 946 RD14B2E271JNBST
R143,144 241 2378 920 RD14B2E221JNBST
R227 241 2379 987 RD14B2E102JNBST
R233 241 2379 987 RD14B2E102JNBST
R237 244 2671 914 RS14B3D153JNBST(S)
R239 241 2378 920 RD14B2E221JNBST
R241 241 2378 946 RD14B2E271JNBST
R243 241 2378 920 RD14B2E221JNBST
R327,328 241 2379 987 RD14B2E102JNBST
R333,334 241 2379 987 RD14B2E102JNBST
R337,338 244 2671 914 RS14B3D153JNBST(S)
R339,340 241 2378 920 RD14B2E221JNBST
R341,342 241 2378 946 RD14B2E271JNBST
R343,344 241 2378 920 RD14B2E221JNBST
R427,428 241 2379 987 RD14B2E102JNBST
R433,434 241 2379 987 RD14B2E102JNBST
R437,438 244 2671 914 RS14B3D153JNBST(S)
R439,440 241 2378 920 RD14B2E221JNBST
R441,442 241 2378 946 RD14B2E271JNBST
R443,444 241 2378 920 RD14B2E221JNBST
R603 241 2376 919 RD14B2E300JNBST
R623,624 241 2376 919 RD14B2E300JNBST
R626 244 2052 931 RS14B3A391JNBST(S)
CAPACITORS GROUP
C109,110 254 4573 981 CE04W1H100MT(RE3)
C111,112 255 1273 944 CQ93M1H221KT(B)
C113,114 255 1273 986 CQ93M1H471JT(B)
C115,116 255 1264 966 CQ93M1H332JT(B)
C117,118 254 4579 707 CE04W1H221MC(RE3)
C119,120 255 4250 964 CQ93P2A330JT(NH2)
C121,122 253 4465 902 CC45SL2H050CT
C123,124 253 4486 907 CC45SL2H470JT
C125,126 255 1275 942 CQ93M2A221KT(B)
C209 254 4573 981 CE04W1H100MT(RE3)
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
