Denon AVR-3805 Service Manual

66
66
AVR-3805 / AVC-3890
C211 255 1273 944 CQ93M1H221KT(B)
C213 255 1273 986 CQ93M1H471JT(B)
C215 255 1264 966 CQ93M1H332JT(B)
C217 254 4579 707 CE04W1H221MC(RE3)
C219 255 4250 964 CQ93P2A330JT(NH2)
C221 253 4465 902 CC45SL2H050CT
C223 253 4486 907 CC45SL2H470JT
C225 255 1275 942 CQ93M2A221KT(B)
C309,310 254 4573 981 CE04W1H100MT(RE3)
C311,312 255 1273 944 CQ93M1H221KT(B)
C313,314 255 1273 986 CQ93M1H471JT(B)
C315,316 255 1264 966 CQ93M1H332JT(B)
C317,318 254 4579 707 CE04W1H221MC(RE3)
C319,320 255 4250 964 CQ93P2A330JT(NH2)
C321,322 253 4465 902 CC45SL2H050CT
C323,324 253 4486 907 CC45SL2H470JT
C325,326 255 1275 942 CQ93M2A221KT(B)
C409,410 254 4573 981 CE04W1H100MT(RE3)
C411,412 255 1273 944 CQ93M1H221KT(B)
C413,414 255 1273 986 CQ93M1H471JT(B)
C415,416 255 1264 966 CQ93M1H332JT(B)
C417,418 254 4579 707 CE04W1H221MC(RE3)
C419,420 255 4250 964 CQ93P2A330JT(NH2)
C421,422 253 4465 902 CC45SL2H050CT
C423,424 253 4486 907 CC45SL2H470JT
C425,426 255 1275 942 CQ93M2A221KT(B)
C525 253 8022 707 CK45F2EAC103MC
C599 254 4367 906 CE04W1J470MT(ASF)
C601-604 255 1279 951 CQ93M1H104JT(B)
C605,606 256 1042 903 CF93A2E104KT
C607 254 4541 939 CE04W1E470MT SMG/RE3
C608 254 4524 969 CE04W1H3R3MT SMG/RE3
C609 254 4573 949 CE04W1H010MT(RE3)
C610 254 6233 708 CE04W1C183MC(SMQ)
C611 256 1042 903 CF93A2E104KT
C613,614 254 4524 943 CE04W1H010MT SMG/RE3
C615,616 254 4573 949 CE04W1H010MT(RE3)
C617 254 4442 708 CE04W1C682MC (SMG)
C618 254 4472 707 CE04W1C472MC (SMG)
C619,620 254 4524 943 CE04W1H010MT SMG/RE3
C622 254 4574 906 CE04W1H330MT(RE3)
C623 254 4580 712 CE04W1H101MC(ROB)
C625 254 4481 918 CE04W2A100MT(ASF)
C626,627 254 4580 712 CE04W1H101MC(ROB)
C628,629 254 4367 906 CE04W1J470MT(ASF)
C630,631 254 6235 706 CE68W1V682M
C636 254 4574 906 CE04W1H330MT(RE3)
C639,640 254 4522 783 CE04W1V471MC SMG/RE3
C641,642 254 4573 949 CE04W1H010MT(RE3)
C643 254 4573 907 CE04W1H0R1MT(RE3)
OTHER PARTS GROUP
CW35,36 205 0697 034 JL CONNECTOR(F-E)
CW44 205 0885 082 4P CON.SOCKET(TUC-P)
CW63-69 205 0942 019 6P CON.SOCKET(TUC-P
CW82 205 0885 095 8P CON.SOCKET(TUC-P)
CW114 205 1229 016 11P FJ CONN.PLUG
CW115 205 0885 066 11P CON.SOCKET TUC-P
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
