Denon AVR-3805 Service Manual

67
67
AVR-3805 / AVC-3890
CW119 205 0885 066 11P CON.SOCKET TUC-P
CW132 205 0942 006 13P CON.SOCKET(TUC-P
CW143 205 1229 029 14P FJ CONN.PLUG
CW152 205 0885 040 15P CON.SOCKET TUC-P
CX21 205 0581 069 2P VH-VH CON BASE
CX22 205 0581 056 2P VH CONNECTOR BASE
CX23 205 1093 006 2P VH CONNECTOR BASA
CX24 205 0581 001 2P VH CONNECTOR BASE
CX62 205 0943 018 6P CON.BASE(TUC-P)
CX71,72 205 0943 021 7P CON.BASE(TUC-P)
CX78 205 1248 013 7P JE CON.PLUG
CX85 205 0343 087 8P CONN.BASE(KR-PH)
CX93 205 0233 090 9P EH CONNECTOR BASE
CX111 205 0884 067 11P CON.BASE TUC-P
CX113 205 0884 067 11P CON.BASE TUC-P
CX116 205 1091 024 11P CON BASE TWG-P
CX153 205 0884 041 15P CON.BASE TUC-P
CX155 205 1248 055 15P JE CON.PLUG
CX156 205 1253 008 15P FFC CONNECTOR-FE
CX193 205 1091 008 19P CON.BASE(TWG-P)
! F1 206 1015 074 FUSE 3.15A
! F8 206 1015 032 FUSE (2.5A)
! F11-15 206 1015 074 FUSE 3.15A
FF501,502 202 0040 909 FUSE CLIP (TAPE)
FF601-605 202 0040 909 FUSE CLIP (TAPE)
FH501,502 202 0040 909 FUSE CLIP (TAPE)
FH601-605 202 0040 909 FUSE CLIP (TAPE)
! RL502 214 0221 006 RELAY TV-8
ST101 205 0452 017 STYLE PIN
ST501 205 1034 007 M3 SCREW TERMINAL
ST601 205 1034 010 M3 SCREW TERMINAL
★
415 0299 000 CONDENSER COVER 1
★
415 0309 026 P.V.C. TUBE(L=20) 2
★
417 0644 004 HEAT SINK 1
★
470 0014 020 3X16 CPS SW W ZNP 1
★
513 3730 048 FUSE LABEL(T2.5AL) 1
★
513 3730 051 FUSE LABEL(T3.15AL) 6
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
