Denon AVR-3805 Service Manual

96
96
AVR-3805 / AVC-3890
CAPACITORS GROUP
C101,102 257 0501 901 CK73B1H103KT (1608)
C103,104 254 4300 963 CE04W0J101MT(SRE)
C105,106 257 0503 941 CC73CH1H120JT
C107,108 257 0504 908 CC73CH1H220JT
C109,110 254 4300 918 CE04W0J100MT(SRE)
C111,112 257 0501 901 CK73B1H103KT (1608)
C113 254 4299 919 CE04W1C220MT(SRE)
C114,115 257 0501 901 CK73B1H103KT (1608)
C116 257 0516 954 CK73B1E104KT
C117,118 257 0501 901 CK73B1H103KT (1608)
C119 257 0508 959 CC73CH1E681JT
C120 257 0516 954 CK73B1E104KT
C121 254 4574 906 CE04W1H330MT(RE3)
C122-128 257 0501 901 CK73B1H103KT (1608)
C129 254 4300 963 CE04W0J101MT(SRE)
C130 257 0503 941 CC73CH1H120JT
C131 254 4299 919 CE04W1C220MT(SRE)
C132,133 257 0501 901 CK73B1H103KT (1608)
C134 257 0503 941 CC73CH1H120JT
C135,136 254 4299 919 CE04W1C220MT(SRE)
C137 254 4305 942 CE04W1HR47MT(SRE)
C138 254 4573 910 CE04W1HR22MT(RE3)
C139 257 3011 948 CF73=1H222JT(ECHUB5)
C140 254 4300 963 CE04W0J101MT(SRE)
C141 257 0501 901 CK73B1H103KT (1608)
C142 254 4573 952 CE04W1H2R2MT(RE3)
C143-146 257 0516 954 CK73B1E104KT
C147,148 254 4300 963 CE04W0J101MT(SRE)
C149 257 0516 954 CK73B1E104KT
C150 254 4573 907 CE04W1H0R1MT(RE3)
C151 254 4573 952 CE04W1H2R2MT(RE3)
C152 257 3014 987 CF73=1C223JT(ECHUB5)
C153-155 254 4573 907 CE04W1H0R1MT(RE3)
C156,157 254 4305 900 CE04W1H0R1MT(SRE)
C158 257 0516 954 CK73B1E104KT
C159 254 4574 906 CE04W1H330MT(RE3)
C160 257 0503 941 CC73CH1H120JT
C161 257 0504 908 CC73CH1H220JT
C162 254 4573 994 CE04W1H220MT(RE3)
C163 254 4536 928 CE04W1A101MT SMG/RE3
C164,165 254 4573 981 CE04W1H100MT(RE3)
C166,167 254 4300 963 CE04W0J101MT(SRE)
C168 254 4574 906 CE04W1H330MT(RE3)
C169-171 257 0501 901 CK73B1H103KT (1608)
C172 257 0504 982 CC73CH1H470JT
C501,502 257 0501 901 CK73B1H103KT (1608)
C503 254 4574 906 CE04W1H330MT(RE3)
C504 257 0501 901 CK73B1H103KT (1608)
C505-508 257 0516 954 CK73B1E104KT
C510 254 4573 936 CE04W1HR47MT(RE3)
C511 257 0516 954 CK73B1E104KT
C513 257 0516 954 CK73B1E104KT
C514 254 4573 936 CE04W1HR47MT(RE3)
C515 254 4573 981 CE04W1H100MT(RE3)
C516 254 4573 949 CE04W1H010MT(RE3)
C517 257 0516 954 CK73B1E104KT
C518 254 4573 949 CE04W1H010MT(RE3)
C519 254 4573 936 CE04W1HR47MT(RE3)
C520 254 4573 949 CE04W1H010MT(RE3)
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
