Denon AVR-3805 Service Manual

97
97
AVR-3805 / AVC-3890
C521 254 4574 906 CE04W1H330MT(RE3)
C522 257 0501 901 CK73B1H103KT (1608)
C523 254 4573 936 CE04W1HR47MT(RE3)
C701 254 4480 906 CE04W0J331MT(ASF)
C702,703 257 0501 901 CK73B1H103KT (1608)
C704,705 257 0516 954 CK73B1E104KT
C706 257 0509 929 CK73B1H102KT
C707 257 0504 937 CC73CH1H300JT
C708 257 0501 901 CK73B1H103KT (1608)
C709,710 257 0516 954 CK73B1E104KT
C711 257 0509 929 CK73B1H102KT
C712 257 0504 937 CC73CH1H300JT
C713 254 4573 981 CE04W1H100MT(RE3)
C714 254 4540 710 CE04W1J471MC SMG/RE3
C715 254 4313 950 CE04W1H101MT(ASF)
C716 257 0517 908 CK73B1C473KT
C717,718 257 0501 901 CK73B1H103KT (1608)
C719 256 1042 903 CF93A2E104KT
C720 254 4313 950 CE04W1H101MT(ASF)
C721 254 4573 981 CE04W1H100MT(RE3)
C722 257 0501 901 CK73B1H103KT (1608)
C723,724 257 0509 929 CK73B1H102KT
C727 257 0517 908 CK73B1C473KT
C728 254 4540 710 CE04W1J471MC SMG/RE3
OTHER PARTS GROUP
AS701 146 2348 008 FLD HOLDER *
CW154 205 0885 040 15P CON.SOCKET TUC-P
CW158 205 0885 040 15P CON.SOCKET TUC-P
CX45 205 0355 046 4P KR CON BASE(L)
CX51 205 0321 054 5P CONNE.BASE (RED)
CX52 205 0343 058 5P CONN.BASE(KR-PH)
CX60 205 0343 061 6P CONN.BASE(KR-PH)
CX961 204 0582 007 6P DA-DA CON.CORD *
CX969 205 0234 060 6P CONN BASE
CY101 205 0375 000 10P CON.BASE(KR-PH)
CY301 205 1006 035 30P FFC BASE(P=1)
CY962 205 0343 061 6P CONN.BASE(KR-PH)
FB101,102 247 2018 903 RM73B--0R0KT
FB103-107 235 0130 903 CHIP EMIFIL(11A121)
FL701 393 8073 009 FLD(32-BT-10GN) *
L101,102 235 0150 938 LQH32MN270J23L
L103 235 0150 954 LQH32MN101J23L
L107 235 0150 938 LQH32MN270J23L
L701 235 0060 989 INDUCTOR(121)ST
ST101,102 205 0452 017 STYLE PIN
X101 399 0809 004 X'TAL(4.43MHZ)
X102 399 0802 001 X'TAL(3.58MHZ)
X103 399 0810 006 CSB503F30
Ref. No. Part No. Part Name Remarks New

Denon AVR-3805 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Speaker selector	A / B
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	160 W
Power output per channel (20-20KHz@8 Ohm)	120 W
AC input voltage	120 V
AC input frequency	60 Hz
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	56
HDMI in	0
Audio (L/R) in	11
Remote control in	1
Composite video in	7
Digital audio coaxial in	2
Digital audio optical in	5
Component video (YPbPr/YCbCr) in	3
AirPlay	No
Display	-
Product color	Black
Audio decoders	DTS 96/24, DTS Neo:6, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), Dolby Digital EX, Dolby Pro Logic IIx
Apple docking compatibility	Not supported
Speakers connectivity type	RCA

Weight and Dimensions

Depth	429 mm
Width	434 mm
Height	171 mm
Weight	17000 g
