Denon AVR-3806 Service Manual

63
AVR-3806 / AVC-3920
CAPACITORS GROUP
C501 nsp 00D 257 0516 954 CK73B1E104KT +1608
C502,503 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C504 nsp 00D 257 0509 929 CK73B1H102KT +1608
C505 nsp 00D 257 0516 954 CK73B1E104KT +1608
C507 00D 254 4666 005 CE04W0H105ZC(FG)
C508 00D 254 4573 981 CE04W1H100MT(RE3)
C509,510 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C540 00D 254 4574 906 CE04W1H330MT(RE3)
C545 nsp 00D 257 0509 929 CK73B1H102KT +1608
C546 00D 254 4533 934 CE04W0J221MT SMG/RE3
C547,548 nsp 00D 257 0503 941 CC73CH1H120JT +1608
C551 nsp 00D 257 0509 929 CK73B1H102KT +1608
C555 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C564 nsp 00D 257 0516 954 CK73B1E104KT +1608
C567 00D 254 4574 906 CE04W1H330MT(RE3)
C570 00D 254 4569 924 CE04W1E101MT(RE3)
C571 nsp 00D 257 0516 954 CK73B1E104KT +1608
C574 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C575 00D 254 4573 978 CE04W1H4R7MT(RE3)
C581 00D 255 1279 951 CQ93M1H104JT(B)
C801-804 00D 254 4573 994 CE04W1H220MT(RE3)
C807-810 00D 254 4573 994 CE04W1H220MT(RE3)
C813-816 00D 254 4573 994 CE04W1H220MT(RE3)
C819-822 00D 254 4573 994 CE04W1H220MT(RE3)
C825-828 00D 254 4573 994 CE04W1H220MT(RE3)
C831-834 00D 254 4573 994 CE04W1H220MT(RE3)
C837 00D 254 4573 949 CE04W1H010MT(RE3)
C838,839 nsp 00D 257 0516 954 CK73B1E104KT +1608
C840 00D 254 4573 949 CE04W1H010MT(RE3)
C841-843 nsp 00D 257 0516 954 CK73B1E104KT +1608
C844-851 nsp 00D 257 0507 976 CC73CH1H331JT +1608
C852-855 nsp 00D 257 0516 954 CK73B1E104KT +1608
C856 00D 254 4573 949 CE04W1H010MT(RE3)
C857-859 00D 254 4573 907 CE04W1H0R1MT(RE3)
C860 00D 254 4573 981 CE04W1H100MT(RE3)
C861-864 00D 254 4573 907 CE04W1H0R1MT(RE3)
C865 00D 254 4574 922 CE04W1H101MT(RE3)
C866 00D 254 4573 907 CE04W1H0R1MT(RE3)
C901,902 00D 247 2018 903 RM73B--0R0KT +1608
C906-910 nsp 00D 257 0516 954 CK73B1E104KT +1608
C911-913 00D 254 4574 906 CE04W1H330MT(RE3)
C914-917 nsp 00D 257 0516 954 CK73B1E104KT +1608
C918-923 00D 254 4573 978 CE04W1H4R7MT(RE3)
C924,925 nsp 00D 257 0516 954 CK73B1E104KT +1608
C926 00D 254 4573 978 CE04W1H4R7MT(RE3)
C929-931 nsp 00D 257 0516 954 CK73B1E104KT +1608
C939,940 00D 254 4573 949 CE04W1H010MT(RE3)
C942 nsp 00D 257 0506 951 CC73CH1H101JT +1608
C944,945 nsp 00D 257 0509 929 CK73B1H102KT +1608
C947-949 nsp 00D 257 0509 929 CK73B1H102KT +1608
C950 00D 254 4573 981 CE04W1H100MT(RE3)
C952,953 nsp 00D 257 0509 929 CK73B1H102KT +1608
OTHERS PARTS GROUP
CW052 nsp 00D 205 0343 058 5P CONN.BASE(KR-PH)
CW053 nsp 00D 205 0321 054 5P CONNE.BASE (RED)
CW114 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
CW119 nsp 00D 205 0885 066 11P CON.SOCKET TUC-P
CW141 nsp 00D 205 0885 011 14P CON.SOCKET TUC-P
CW145 nsp 00D 205 1229 029 14P FJ CONN.PLUG
CW151,152 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW157 nsp 00D 205 0885 040 15P CON.SOCKET TUC-P
CW161 nsp 00D 205 0942 051 16P CON.SOCKET TUC-P
CW912,913 nsp 00D 205 1249 038 11P JE CON.BASE
Ref. No. nsp Part No. Part Name Remarks Q'ty New
