68
AVR-3806 / AVC-3920
1U-3702 P. SUPPLY P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC601 00D 263 1048 002 BA033T
IC602 00D 263 1092 003 BA05T
IC603 00D 263 0554 005 NJM7905FA
IC604 00D 263 1100 047 KIA7820API
IC605 00D 263 1100 005 KIA7805API
IC606,607 00D 263 1048 002 BA033T
IC608 00D 279 0034 067 PTH9M04BB222TS2F333
IC610 00D 263 1092 003 BA05T
IC832 00D 263 1163 000 KIA78R09PI
TR107-110 00D 271 0301 903 2SA/KTA1268BL-AT
TR111,112 00D 273 0471 907 KTC3206Y-AT
TR113,114 00D 271 0314 903 KTA1024Y-AT
TR115,116 00D 273 0471 907 KTC3206Y-AT
TR207 00D 271 0301 903 2SA/KTA1268BL-AT
TR209 00D 271 0301 903 2SA/KTA1268BL-AT
TR211 00D 273 0471 907 KTC3206Y-AT
TR213 00D 271 0314 903 KTA1024Y-AT
TR215 00D 273 0471 907 KTC3206Y-AT
TR307-310 00D 271 0301 903 2SA/KTA1268BL-AT
TR311,312 00D 273 0471 907 KTC3206Y-AT
TR313,314 00D 271 0314 903 KTA1024Y-AT
TR315,316 00D 273 0471 907 KTC3206Y-AT
TR407-410 00D 271 0301 903 2SA/KTA1268BL-AT
TR411,412 00D 273 0471 907 KTC3206Y-AT
TR413,414 00D 271 0314 903 KTA1024Y-AT
TR415,416 00D 273 0471 907 KTC3206Y-AT
TR601 00D 271 0313 904 KTA1281Y-AT
TR602 00D 269 0206 908 KRC102M-AT(10K-10K)
TR603 00D 272 0158 007 2SB/KTB778(R/O)
TR604,605 00D 271 0313 904 KTA1281Y-AT
TR606 00D 273 0469 906 2SC/KTC3209Y-AT
TR607 00D 269 0206 908 KRC102M-AT(10K-10K)
TR608 00D 271 0311 906 2SA/KTA1267GR-AT
TR609 00D 269 0206 908 KRC102M-AT(10K-10K)
TR610 00D 271 0313 904 KTA1281Y-AT
TR611 00D 269 0206 908 KRC102M-AT(10K-10K)
TR613 00D 274 0198 005 2SD/KTD998(R/O)
TR614 00D 272 0158 007 2SB/KTB778(R/O)
TR615 00D 273 0468 907 2SC/KTC3199GR-AT
TR616 00D 271 0311 906 2SA/KTA1267GR-AT
TR619 00D 272 0158 007 2SB/KTB778(R/O)
TR620 00D 271 0313 904 KTA1281Y-AT
TR621 00D 273 0468 907 2SC/KTC3199GR-AT
TR622 00D 272 0158 007 2SB/KTB778(R/O)
TR623 00D 274 0198 005 2SD/KTD998(R/O)
TR625 00D 269 0206 908 KRC102M-AT(10K-10K)
TR627 00D 272 0158 007 2SB/KTB778(R/O)
TR628 00D 271 0313 904 KTA1281Y-AT
TR629 00D 269 0206 908 KRC102M-AT(10K-10K)
TR701 00D 271 0301 903 2SA/KTA1268BL-AT
TR702,703 00D 273 0464 901 KTC3875SGR-RTK +C
TR704 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR705,706 00D 273 0464 901 KTC3875SGR-RTK +C
TR707 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR708,709 00D 273 0464 901 KTC3875SGR-RTK +C
TR710 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR711,712 00D 273 0464 901 KTC3875SGR-RTK +C
D101-106 00D 276 0432 903 1SS270A TE (TAPE)
D201 00D 276 0432 903 1SS270A TE (TAPE)

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
