Denon AVR-3806 Service Manual

70
AVR-3806 / AVC-3920
C209 00D 254 4573 981 CE04W1H100MT(RE3)
C211 00D 255 1273 944 CQ93M1H221KT(B)
C213 00D 255 1273 986 CQ93M1H471JT(B)
C215 00D 255 1264 966 CQ93M1H332JT(B)
C217 00D 254 4579 707 CE04W1H221MC(RE3)
C219 00D 253 4552 909 CC45SL2H330JT
C221 00D 253 4550 901 CC45SL2H050CT
C223 00D 253 4551 900 CC45SL2H470JT
C225 00D 255 1275 942 CQ93M2A221KT(B)
C309,310 00D 254 4573 981 CE04W1H100MT(RE3)
C311,312 00D 255 1273 944 CQ93M1H221KT(B)
C313,314 00D 255 1273 986 CQ93M1H471JT(B)
C315,316 00D 255 1264 966 CQ93M1H332JT(B)
C317,318 00D 254 4579 707 CE04W1H221MC(RE3)
C319,320 00D 253 4552 909 CC45SL2H330JT
C321,322 00D 253 4550 901 CC45SL2H050CT
C323,324 00D 253 4551 900 CC45SL2H470JT
C325,326 00D 255 1275 942 CQ93M2A221KT(B)
C409,410 00D 254 4573 981 CE04W1H100MT(RE3)
C411,412 00D 255 1273 944 CQ93M1H221KT(B)
C413,414 00D 255 1273 986 CQ93M1H471JT(B)
C415,416 00D 255 1264 966 CQ93M1H332JT(B)
C417,418 00D 254 4579 707 CE04W1H221MC(RE3)
C419,420 00D 253 4552 909 CC45SL2H330JT
C421,422 00D 253 4550 901 CC45SL2H050CT
C423,424 00D 253 4551 900 CC45SL2H470JT
C425,426 00D 255 1275 942 CQ93M2A221KT(B)
C599 00D 254 4347 748 CE04W1H010MC(ARSA)
C601 00D 254 4577 945 CE04W1C101MT(RE3)
C602-606 00D 255 1279 951 CQ93M1H104JT(B)
C607 00D 254 4569 911 CE04W1E470MT(RE3)
C608 00D 254 4573 965 CE04W1H3R3MT(RE3)
C609 00D 257 0509 929 CK73B1H102KT +1608
C610 00D 254 4760 707 CE04W1E103MC(SMQ)
C611 00D 256 1042 903 CF93A2E104KT
C612 00D 254 4569 911 CE04W1E470MT(RE3)
C613-616 00D 254 4573 949 CE04W1H010MT(RE3)
C617,618 00D 254 4761 706 CE04W1C153MC(SMQ)
C619,620 00D 254 4573 949 CE04W1H010MT(RE3)
C621 00D 254 4573 965 CE04W1H3R3MT(RE3)
C622 00D 254 4573 981 CE04W1H100MT(RE3)
C623 00D 254 4569 924 CE04W1E101MT(RE3)
C624 00D 254 4569 911 CE04W1E470MT(RE3)
C625 00D 254 4573 949 CE04W1H010MT(RE3)
C626,627 00D 254 4569 937 CE04W1E221MT(RE3)
C628,629 00D 254 4573 981 CE04W1H100MT(RE3)
C630,631 00D 254 6258 000 CE68W1V822M
C632 00D 254 4573 949 CE04W1H010MT(RE3)
C633 00D 254 4761 719 CE04W1C223MC(SMQ)
C634 00D 255 1279 951 CQ93M1H104JT(B)
C635 00D 254 4569 911 CE04W1E470MT(RE3)
C636 00D 254 4573 965 CE04W1H3R3MT(RE3)
C637 00D 254 4573 949 CE04W1H010MT(RE3)
C638 00D 254 4761 719 CE04W1C223MC(SMQ)
C639,640 00D 254 4428 706 CE04W1V222MC (SMG)
C641,642 00D 254 4573 949 CE04W1H010MT(RE3)
C643 00D 254 4573 907 CE04W1H0R1MT(RE3)
C647 00D 254 4573 949 CE04W1H010MT(RE3)
C648 nsp 00D 257 0509 929 CK73B1H102KT +1608
C649 00D 254 4569 924 CE04W1E101MT(RE3)
C650 00D 254 4761 722 CE04W1C822MC(SMQ)
C651 00D 254 4761 706 CE04W1C153MC(SMQ)
C701 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C702 00D 254 4573 981 CE04W1H100MT(RE3)
C703 nsp 00D 257 0516 954 CK73B1E104KT +1608
C704 00D 254 4533 947 CE04W0J331MT SMG/RE3
C705 nsp 00D 257 0516 954 CK73B1E104KT +1608
Ref. No. nsp Part No. Part Name Remarks Q'ty New

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
