Denon AVR-3806 Service Manual

72
AVR-3806 / AVC-3920
1U-3703 FRONT P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 499 0303 004 GP1UM271XK
! IC102 00D 268 0073 905 ICP-N15T
IC103,104 00D 262 3572 007 PT6302LQ-001(L)
IC401,402 00D 263 1082 903 TK15420MTL +C
IC403 00D 262 0707 901 TC4053BF (TAPE) +C
IC404 00D 262 2643 908 TC4052BF(TAPE)
IC405,406 00D 262 3336 900 TC4051BF
IC407 00D 263 1082 903 TK15420MTL +C
IC701 00D 262 2580 906 CXA1511M +C
IC705 00D 262 3571 901 HIN202EIBNZ-T
IC802 00D 263 0896 909 NJM2068MD-TE1 +C
IC804 00D 263 0896 909 NJM2068MD-TE1 +C
TR101 00D 269 0191 903 KRA104S-RTK(47K-47K) +C
TR102 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR103 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR104 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR105 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR106 00D 271 0316 901 KTA1042D +C
TR301 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR302,303 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR304,305 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR371-373 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR401,402 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR403 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR701 00D 269 0191 903 KRA104S-RTK(47K-47K) +C
TR702,703 00D 269 0193 901 KRC104S-RTK(47K-47K) +C
TR704,705 00D 269 0191 903 KRA104S-RTK(47K-47K) +C
D101 00D 276 0704 903 1SR35-400A(T93X)
D103,104 00D 276 0794 900 KDS160 +2125
D401,402 00D 276 0794 900 KDS160 +2125
ZD101 00D 276 0683 956 UDZS15B-TE17 +C
ZD102 00D 276 0683 998 UDZS16B-TE17 +C
ZD103 00D 276 0798 951 UDZS4.7B-TE17
ZD108 00D 276 0798 951 UDZS4.7B-TE17
ZD701 00D 276 0798 906 UDZS6.2B-TE17
ZD702,703 00D 276 0683 998 UDZS16B-TE17 +C
LD101 00D 393 9645 009 SML1216W(D)
LD301 00D 393 9645 009 SML1216W(D)
LD302 00D 393 9662 901 SEL1410ETP2(D2/D3)
LD371-373 00D 393 9662 901 SEL1410ETP2(D2/D3)
CAPACITORS GROUP
C101 00D 255 1279 951 CQ93M1H104JT(B)
C102 00D 254 4574 922 CE04W1H101MT(RE3)
C103 nsp 00D 257 0516 954 CK73B1E104KT +1608
C104 00D 254 4574 922 CE04W1H101MT(RE3)
C106 00D 254 4573 981 CE04W1H100MT(RE3)
C108 00D 255 1279 951 CQ93M1H104JT(B)
C109 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C110,111 nsp 00D 257 0516 954 CK73B1E104KT +1608
C112,113 nsp 00D 257 0509 929 CK73B1H102KT +1608
C115,116 00D 254 4540 710 CE04W1J471MC SMG/RE3
C117,118 nsp 00D 257 0516 954 CK73B1E104KT +1608
C119 nsp 00D 257 0501 901 CK73B1H103KT (1608) +1608
C120,121 nsp 00D 257 0516 954 CK73B1E104KT +1608
C122,123 nsp 00D 257 0509 929 CK73B1H102KT +1608
C124 nsp 00D 257 0504 982 CC73CH1H470JT +1608

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
