Denon AVR-3806 Service Manual

75
AVR-3806 / AVC-3920
1U-3704 AUDIO / VIDEO P.W.B. UNIT ASS'Y
Ref. No. nsp Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 00D 262 3551 002 NJW1321FP1
IC102,103 00D 263 1225 906 NJM2581M-TE1
IC201-204 00D 262 3168 903 TC94A32F +C
IC205 00D 262 3556 900 TC9459BFG
IC206 00D 263 0615 902 BA15218F-DXE2 +C
IC207-210 00D 262 3555 901 SA5532ADR
IC301-304 00D 263 1082 903 TK15420MTL +C
IC305,306 00D 262 3447 909 TC4053BFT
IC307 00D 262 3446 900 TC4052BFT
IC308-311 00D 262 3445 901 TC4051BFT
IC312,313 00D 263 1082 903 TK15420MTL +C
IC401 00D 262 2725 004 TC9273N-015
IC403,404 00D 263 0615 902 BA15218F-DXE2 +C
IC406 00D 262 3347 009 TC94A46FG +C
IC407 00D 263 0896 909 NJM2068MD-TE1 +C
IC408 00D 263 1098 900 LM833MX
IC409-416 00D 263 0896 909 NJM2068MD-TE1 +C
IC501 00D 262 2919 001 TC9274N-017
IC701 00D 262 2827 902 MM74HC4053SJ +C
IC702 00D 262 1671 900 NJM2229M-TE1
IC703 00D 262 3450 006 M35015-***SP
IC704 00D 262 3447 909 TC4053BFT
IC705-707 00D 263 1082 903 TK15420MTL +C
IC708-710 00D 263 1197 908 BU4094BCFV-E2
IC901 00D 263 1205 900 PQ012FZ01ZP +C
IC914 00D 262 3106 907 SN65LVDS32PW +REF
IC915 00D 262 3432 901 SN65LVDS1DBVR
IC916 00D 269 0221 006 GP1FM313RZ
IC917 00D 263 0615 902 BA15218F-DXE2 +C
TR101 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR102 00D 269 0144 905 DTC114YK-T146 +C
TR103 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR301 00D 271 0312 905 2SA/KTA1504SGR-RTK +C
TR302,303 00D 269 0192 902 KRC102S-RTK(10K-10K) +C
TR501-520 00D 273 0460 905 KTC2875B-RTK +C
TR525-528 00D 273 0460 905 KTC2875B-RTK +C
TR701,702 00D 273 0464 901 KTC3875SGR-RTK +C
TR810 00D 273 0458 904 2SC/KTC3200BL-AT
TR811,812 00D 271 0301 903 2SA/KTA1268BL-AT
TR813 00D 274 0160 907 2SD2144STPU
TR814,815 00D 271 0301 903 2SA/KTA1268BL-AT
TR816 00D 273 0458 904 2SC/KTC3200BL-AT
D101,102 00D 276 0794 900 KDS160 +2125
D301,302 00D 276 0794 900 KDS160 +2125
D701 00D 276 0740 909 KDS184-RTK(K-COM) +C
D702 00D 276 0794 900 KDS160 +2125
D815 00D 276 0794 900 KDS160 +2125
D816-829 00D 276 0773 905 RB501V-40 +2125
ZD901-904 00D 276 0829 901 NSAD500F-T1B
ZD905-907 00D 276 0683 930 UDZS5.1B-TE17 +C
X701 00D 399 0739 006 X'TAL(14.32M-RIBER)
X702 00D 399 0105 009 CSB503F2
RESISTORS GROUP
R877 00D 241 2383 902 RD14B2E223JNBST
