Denon AVR-3806 Service Manual

87
AVR-3806 / AVC-3920
EXPLODED VIEW (2/2) (FRONT PANEL UNIT)
50
51
52
54
55
56
56
57
57
58
59
60
61
62
63
64
65
66
75
67
68
69
70
71
72
73
74
100
100
102
102
102
100
100
100
100
100
100
100
100
100
111
100
100
101
100
101
102
103
103
120
120
100
101
4-4
4-1
4-2
4-3
4-8
4-9
5-3
5-4
4-7
4-5
H/P PLATE : Cut INNER PANEL
D/S PLATE : Cut INNER PANEL
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。

Denon AVR-3806 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Component Video Inputs	3
Component Video Outputs	1
Digital Audio Inputs	5 (3 Optical, 2 Coaxial)
THX Certified	No
Dimensions (W x H x D)	434 x 171 x 429 mm
Frequency Response	10 Hz - 100 kHz (+1, -3 dB)
Total Harmonic Distortion	0.05%
Input Sensitivity/Impedance	200 mV/47 kOhms
Signal-to-Noise Ratio	102 dB
Digital Audio Outputs	1 optical
Surround Sound Formats	Dolby Digital, Dolby Pro Logic IIx, DTS
Video Inputs/Outputs	Composite, S-Video, Component
Analog Audio Inputs	9 stereo pairs
Multi-Room Zones	3
Weight	15 kg
