Denon AVR-3806 Service Manual

89
AVR-3806 / AVC-3920
25 nsp 00D 412 5272 007 RADIATOR BRACKET (R) 1 *
26 nsp 00D 412 2814 028 CARD SPACER(L=10) 16
27 nsp 00D 415 0980 005 INSULATING SHEET(B) 1 *
28 nsp 00D 479 0003 038 PUSH RIVET 3
29 nsp 00D 105 1654 006 BACK PANEL 1 *
30 nsp 00D 449 0202 032 LOCKING CARD SPACER 1
31 nsp 00D 205 1116 006 TERMINAL ASS 1
32 00D 216 0124 002 AM FM TUNER(E3) BKEU,SREU,BKEC,SREC,EUT 1
! 33 00D 203 3996 008 AC INLET (2P) 1
! 34 00D 233 6523 000 POWER TRANS(3806E3) 1 *
35 nsp 00D 461 0415 007 RUBBER SHEET 2
36 nsp 00D 415 0979 003 INSULATING SHEET(A) 1 *
37 nsp 00D 461 1227 016 RUBBER FOAM 1 *
38 nsp 00D 461 1182 070 RUBBER SHEET 2 *
39 nsp 00D 461 0573 033 RUBBER SHEET 1
40 nsp 00D GEN 8016 TOP COVER BKEU,BKEC
00D1020671065
1 *
40 nsp 00D GEN 8616 -1 TOP COVER SREU,SREC
00D1020671078
1 *
41 nsp 00D 146 2361 001 SCREW COVER 1
45 00D 278 0013 001 DHCT-A3/C3 7 *
45-1 - DHCT-A3
TR103,104,203,303,304,403,404 00D2720172009
*
45-2 - DHCT-C3
TR101,102,201,301,302,401,402 00D2740210006
*
50 00D 146 2444 009 INNER PANEL BKEU,BKEC 1 *
50 00D 146 2444 012 INNER PANEL SREU,SREC 1 *
51 00D 143 1216 006 DISPLAY SHEET 1
52 00D 143 1189 007 POWER LENS 1
54 00D 146 2347 203 INNER FRAME BKEU,BKEC 1 *
54 00D 146 2347 216 INNER FRAME SREU,SREC 1 *
55 00D 143 1234 004 DOOR SHEET BKEU,BKEC 1 *
55 00D 143 1234 017 DOOR SHEET SREU,SREC 1 *
56 nsp 00D 461 1182 012 RUBBER SHEET 2
57 nsp 00D 461 1182 009 RUBBER SHEET 2
58 00D 143 1233 306 WINDOW BKEU,BKEC 1 *
58 00D 143 1233 319 WINDOW SREU,SREC 1 *
59 00D 113 1992 109 P.KNOB ASSY(SUB) BKEU,BKEC 1
59 00D 113 1992 112 P.KNOB ASSY(SUB) SREU,SREC 1
60 00D 113 1996 202 CURSOR KNOB BKEU,BKEC 1
60 00D 113 1996 215 CURSOR KNOB SREU,SREC 1
61 00D 113 1995 009 ENTER KNOB BKEU,BKEC 1
61 00D 113 1995 012 ENTER KNOB SREU,SREC 1
62 00D 421 0763 010 GEAR DAMPER 1
63 00D 113 1994 107 P.KNOB ASSY(MAIN) BKEU,BKEC 1
63 00D 113 1994 110 P.KNOB ASSY(MAIN) SREU,SREC 1
64 nsp 00D 461 1186 005 SPACER 1
65 nsp 00D 412 5083 102 DOOR STOPPER 1
66 nsp 00D 411 2088 000 FRONT CHASSIS 1 *
67 00D 144 2969 009 FRONT PANEL BKEU,BKEC 1 *
67 00D 144 2969 012 FRONT PANEL SREU,SREC 1 *
68 nsp 00D 131 0158 007 DENON BADGE BKEU,BKEC 1
68 nsp 00D 131 0158 023 DENON BADGE SREU,SREC 1
69 nsp 00D 143 1232 006 LENS 3 *
70 00D 144 2875 106 DOOR ASS'Y BKEU,BKEC 1
70 00D 144 2875 119 DOOR ASS'Y SREU,SREC 1
71 00D 401 0195 202 HINGE (L) BKEU,BKEC 1
71 00D 401 0195 215 HINGE (L) SREU,SREC 1
72 00D 401 0196 201 HINGE (R) BKEU,BKEC 1
72 00D 401 0196 214 HINGE (R) SREU,SREC 1
73 00D 112 0929 002 KNOB (M) ASS'Y BKEU,BKEC 1
73 00D 112 0929 015 KNOB (M) ASS'Y SREU,SREC 1
74 00D 112 0931 003 KNOB (F) ASS'Y BKEU,BKEC 1
74 00D 112 0931 016 KNOB (F) ASS'Y SREU,SREC 1
75 nsp 00D 415 0982 003 FFC COVER 1 *
* nsp 00D 513 4104 000 FUSE CAUTION LABEL 1 *
* nsp 00D 445 8004 007 WIRE CLAMPER 9
* nsp 00D 203 2440 018 2P VA CORD 1
* nsp 00D 513 3333 005 LABEL (TRANS) 1
* nsp 00D GEN 8011 LICENSE SUB ASSY 1 *
* nsp 00D 113 1945 004 RJ45 DUST COVER 1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
