34
DHT-390XP AVR-390
No. Pin Name Pin Symbol I/O Pin Description
29 P70/KR0 1153_LATCH O Chip select output for NJW1153
30 P06/TI011/TO01 1153_CLK O Clock signal output for NJW1153
31 P05/TI001/SSI11 1153_DATA O Output for NJW1153 control data
32 P32/INTP3 P32 Port for ash upgrade
33 P31/INTP2 P31 Port for ash upgrade
34 P50 DSP/DIR_SCL O Clock signal output for DIR/DSP/HDMI
35 P51 DSP/DIR/HDMI_SDA I/O Input & output for DIR/DSP/HDMI control data
36 P52 DIR_PDN O Output for DIR power down
37 P53 DSP_FINTERQ I Output for CS49400 Interrupt Request
38 P30/INTP1 DSP_FCS O Output for CS49400 Chip Select
39 P17/TI50/TO05 DSP_SCDOUT O Output for CS49400 Serial Data Out
40 P16/TOH1/INTP5 DSP_INTERQ I Output for CS49400 Interrupt Request
41 P15/TOH0 DSP_RESET O Output for CS49400 reset
42 P14/RXD6 DSP_SCS/RX O/I Output for CS49400 Chip Select/Input for Upgrade
43 P13/TXD6 VIDEO_SEL1/TX O Output for video function IC switching/Output for Upgrade
44 P12/SO10 VIDEO_SEL2 O Output for video function IC switching
45 P11/SI10/RXD0 i_POD_RX I Input for iPOD RX
46 P10/SCK10/TXD0 i_POD_TX O Output for iPOD TX
47 AVREF AVREF 3V3
48 AVSS AVSS GROUND
49 P27/ANI7 KEY1 I Input for KEY1 scan
50 P26/ANI6 KEY2 I Input for KEY2 scan
51 P25/ANI5 KEY3 I Input for KEY3 scan
52 P24/ANI4 HDMI_RESET O Output for HDMI RESET
53 P23/ANI3 HDMI_HPD0/SEL1 O Output for HDMI_HPD0/SEL1
54 P22/ANI2 HDMI_HPD1/SEL0 O Output for HDMI_HPD1/SEL0
55 P21/ANI1 i_POD_DET I Input for iPOD signal detection
56 P20/ANI0 ST/BY_RLY
O Ouput for standby relay
57 P130 FLT_CE O Chip select output for FLT
58 P04/SCK11 RDS_DATA I iutput for RDS_DATA
59 P03/S111 SET_OPTION I Input for set option data
60 P02/S011 FLT/PLL_OUT O Output for FLT/PLL_control data
61 P01/TI010/TO00 FLT/PLL_CLK O Clock signal output for FLT/PLL
62 P00/TI000 RMC I Input for remocon data
63 P141/BUZ/INTP7 RDS_CLK O Clock signal output for RDS
64 P140/PCL/INTP6 POWER_DOWN I Input for power down
