Denon AVR-390 Service Manual

53
DHT-390XP
AVR-390
C160SL nsp C,FILM 0.1UF-J/100V D02010406C060S
C160SR nsp C,FILM 0.1UF-J/100V D02010406C060S
C161C nsp C,CERAMIC UP025 F223Z-B-BZ E2 D005223594521S
C161L nsp C,CERAMIC UP025 F223Z-B-BZ E2 D005223594521S
C161R nsp C,CERAMIC UP025 F223Z-B-BZ E2 D005223594521S
C161SL nsp C,CERAMIC UP025 F223Z-B-BZ E2 D005223594521S
C161SR nsp C,CERAMIC UP025 F223Z-B-BZ E2 D005223594521S
C162C nsp C,FILM 0.1UF-J/100V E2 D02010406C060S
C162L nsp C,FILM 0.1UF-J/100V E2 D02010406C060S
C162R nsp C,FILM 0.1UF-J/100V E2 D02010406C060S
C162SL nsp C,FILM 0.1UF-J/100V E2 D02010406C060S
C162SR nsp C,FILM 0.1UF-J/100V E2 D02010406C060S
C164SW nsp C,CERAMIC 100PF-J/50V D010101167160S
C167 00D9630294106 C,ELECT 2.2UF-M/50V (Pb Free) D0402R2087160S
C168-170 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C171-174 nsp C,CERAMIC 100PF-J/50V D010101167160S
C175 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C176 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C178 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C179,180 C,ELECT 6800UF-M/63V D040682088010S
C182-184 00D9639003097 C,FILM 0.1UF-K/250V D02010407H080S
C185,186 nsp C,FILM 0.1UF-J/100V D02010406C060S
C187,188 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C189 00D9630065209 C,ELECT 330UF-M/63V D040331088230S
C190 00D9609010010 C,ELECT 4.7UF-M/50V D0404R7087250S
C191 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C192 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C193 963134003210S C,ELECT 220UF-M/10V (Pb Free) D040221082090S
C194 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C195 963134003210S C,ELECT 220UF-M/10V (Pb Free) D040221082090S
C196 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C197 00D9630293709 C,ELECT 100UF-M/10V D040101082070S
C200 00D9630021104 C,ELECT 6800UF-M/16V D040682083000S
C201-203 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C204,205 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C206 00D9630183301 C,ELECT 4700UF-M/25V D040472084020S
C207 00D9630324102 C,ELECT 1000UF-M/25V(SHL) D040102084060S
C208-210 00D9630021900 C,FILM 0.047UF-J/100V D02047306C060S
C211 00D9609010023 C,ELECT 0.47UF-M/50V D040R47087050S
C212 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C213 00D9630294106 C,ELECT 2.2UF-M/50V (Pb Free) D0402R2087160S
C214 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C215,216 nsp C,CERAMIC 100PF-J/50V D010101167160S
C217 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C218,219 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C220 nsp C,CERAMIC 0.047UF-K/16V D011473773160S
C221 00D9600298802 C,ELECT 470UF-M/6.3V D040471081070S
C222 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C223 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C224SW 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C231-233 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C717 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C723,724 nsp C,CERAMIC 220PF-J/50V D010221167160S
C725-727 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
