Denon AVR-390 Service Manual

54
DHT-390XP
AVR-390
OTHERS PARTS GROUP
BD101,102 00D9600197107 D,RECTIFIER BRIDGE KBPC604
K047604000020S
CLAMP201 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP301 nsp CLAMP WIRE(SOLDER) 4330000120000S
CLAMP401 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN701 nsp CN,WIRE 2MM 400MM/5P L002401050030S
CP101 nsp CN.WAFER 3CKT L108353280360S
CP102 nsp CN.WAFER 2.5MM 6P L102526700600S
CP103 nsp CN.FPC 1.25MM 7P L131007100010S
CP104 nsp CN.WAFER 2.0MM L101200100510S
CP106 nsp CN.WAFER 9P L101200100910S
CP107 nsp CN.WAFER 2.5MM 3P L102526700300S
CP110 nsp CN.WAFER 2.0MM L101200101010S
CP111 nsp CN.WAFER 2.5MM 13P L102526701300S
CP201 nsp CN.WAFER 7P L101100040710S
CP401 nsp CN.WAFER 15P L101100041510S
CP402 nsp CN.WAFER 18P L101100041810S
CP403 nsp CN.WAFER 5P L101100040510S
CP701 nsp CN.WAFER 2.0MM L101200100510S
CP705 nsp CN.WAFER 2.0MM L101200100520S
GND101 nsp TERMINAL EARTH 3790040886000S
GND101B nsp TERMINAL EARTH 3790040886000S
JACK101 963643003100S TER 6PIN RCA-610D-00-43 G603610D0043YS
JACK102 963643003110S TER 6PIN RCA-610D-00-01 G603610D0001YS
JACK103 963643003120S TER 9PIN RCA902AD-00-47 G607902AD047YS
JK701 00D9630294708 JACK,D6.5 PHONE G402PJ612AG0YS
RLY101-103 963682002440S RELAY G5PA-28-MC 12V 5A G680120502050S
RLY104 00D9630218409 RELAY BC3-12 24V 2A G680240202030S
SW723 00D9630095305 SW,TACT SKHV10910D01 G180040500010S
X201 963129003130S RESONATOR,CERAMIC ZTT10.00MT E830100000060S
PACK101 963183002880S TUNER,FM/AM KST-MU104MV E3 E903000000050S
PACK101 963183002960S TUNER,FM/AM KST-MU104MV E2 E903104100050S
FPC701A nsp CN 1.25MM 19P L131111900010S
nsp HEAT SINK P656(DOM)AL6063 40MM/SUB 2120000818020S
nsp HEAT SINK HEAT SINK REG TR(24X60) 2120044308010S
nsp SCREW(3X8 B-TYPE ZNY/BH) B020030081B10S
00D9630158608 TER,BOARD SCREW 2P G611201A0200YS
963646001690S TER,BOARD SCREW 8P G614108V1010MS
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-390 Specifications

General

Signal-To-Noise Ratio	98 dB
Total Harmonic Distortion	0.08 %
Input Sensitivity	200 mV
Tuner Bands	AM/FM
Wi-Fi	No
Input Impedance	47k ohms
Inputs	Digital coaxial x 1
Outputs	HDMI x 1
